Ferrari SF90 Spider — [VEHICLE TRIM] - E.26 - REAR SCREEN (diagram 0125)
Exploded view of the [vehicle trim] - e.26 - rear screen on the Ferrari SF90 Spider, with 14 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Spider [VEHICLE TRIM] - E.26 - REAR SCREEN exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-spider/0125.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 13046012 | Ferrari Nut - 13046012 | Superseded | Order 13046011 instead | |
| 1 | 853233 | Ferrari Cristallo Lunotto Scendente - 853233 | $1,116.19 | Contact us to order |
| 1 | 941704 | Ferrari Cristallo Lunotto Scendente - 941704 | $1,116.19 | Contact us to order |
| 2 | 857099 | Ferrari Guarnizione Interna Lunot. S - 857099 | $569.02 | Special order, ships in 7-14 days |
| 3 | 13046011 | Ferrari Flanged Nut - 13046011 | $0.73 | Available, ships in 3-6 days |
| 3 | 14040514 | Ferrari Flanged Nut - 14040514 | Superseded | Order 13046011 instead |
| 4 | 857101 | Ferrari Guarnizione Esterna Lunot. S - 857101 | $590.91 | Special order, ships in 7-14 days |
| 5 | 84413000 | Ferrari Plate - 84413000 | $24.02 | Special order, ships in 7-14 days |
| 6 | 84413900 | Ferrari Shim - 84413900 | $5.44 | Special order, ships in 7-14 days |
| 7 | 85422500 | Ferrari Shim - 85422500 | $8.93 | Special order, ships in 7-14 days |
| 8 | 900536 | Ferrari Alzalunotto Post. Cs - 900536 | $1,488.27 | Special order, ships in 7-14 days |
| 9 | 84801200 | Ferrari Adhesive Strip - 84801200 | $13.99 | Special order, ships in 7-14 days |
| 10 | 13832101 | Ferrari Flanged Nut M6 - 13832101 | $0.27 | Available, ships in 3-6 days |
| 11 | 14059121 | Ferrari Nut M5 - 14059121 | $0.31 | Available, ships in 3-6 days |
