Ferrari SF90 Spider — [VEHICLE TRIM] - E.34 - FRONT LID LOCK (diagram 0135)
Exploded view of the [vehicle trim] - e.34 - front lid lock on the Ferrari SF90 Spider, with 19 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Spider [VEHICLE TRIM] - E.34 - FRONT LID LOCK exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-spider/0135.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 11087675 | Ferrari Circlip - 11087675 | Superseded | Order 11087676 instead | |
| 248061 | Ferrari Clip - 248061 | $4.12 | Available, ships in 3-6 days | |
| 20035903 | Ferrari Door Lock Circlips - 20035903 | Superseded | Order 11087676 instead | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 1 | 879339 | Ferrari Complete Front Lid Lock - USA - 879339 | $1,875.98 | Special order, ships in 7-14 days |
| 1 | 968634 | Ferrari Serratura Cofano Ant Cpl - 968634 | $960.25 | Contact us to order |
| 2 | 873573 | Ferrari Bowden Ap Ch Serratura Cofan - 873573 | $135.39 | Special order, ships in 7-14 days |
| 2 | 900848 | Ferrari Front Lid Lock Release Bowde - 900848 | $123.09 | Special order, ships in 7-14 days |
| 3 | 13027026 | Ferrari Screw M6 x 16 TCEI - 13027026 | $2.01 | Available, ships in 3-6 days |
| 3 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 4 | 11194674 | Ferrari Washer - 11194674 | $0.92 | Available, ships in 3-6 days |
| 5 | 14496101 | Ferrari Washer - 14496101 | $0.12 | Available, ships in 3-6 days |
| 6 | 11087476 | Ferrari Circlip - 11087476 | $11.35 | Available, ships in 3-6 days |
| 7 | 11087676 | Ferrari Circlip - 11087676 | $0.27 | Available, ships in 3-6 days |
| 8 | 14569480 | Ferrari Clip 10x3.8 Black - 14569480 | $0.54 | Available, ships in 3-6 days |
| 9 | 242384 | Ferrari Clip - 242384 | $0.59 | Available, ships in 3-6 days |
| 10 | 11223887 | Ferrari Clip - 11223887 | $1.02 | Special order, ships in 7-14 days |
| 11 | 777876 | Ferrari Child Safety Release Bowden - 777876 | $88.61 | Special order, ships in 7-14 days |
| 12 | 67053000 | Ferrari Boot Safety Handle - 67053000 | $66.35 | Special order, ships in 7-14 days |
