Ferrari SF90 Spider — [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS (diagram 0157)

Exploded view of the [vehicle trim] - e.47.09 - dashboard - fasteners on the Ferrari SF90 Spider, with 62 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari SF90 Spider [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
290589Ferrari Screw 4x8 - 290589SupersededOrder 309629 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
12638108Ferrari Washer - 12638108SupersededOrder 12638178 instead
12638177Ferrari Washer - 12638177SupersededOrder 12638178 instead
61276300Ferrari Washer - 61276300SupersededOrder 12638178 instead
13337547Ferrari Washer D.5 - 13337547SupersededOrder 12642821 instead
112626221Ferrari Washer - 12626221SupersededOrder 12626224 instead
112626224Ferrari Washer - 12626224$0.38Available, ships in 3-6 days
2898398Ferrari Screw - 898398$11.77Special order, ships in 7-14 days
367278400Ferrari BRACKET - 67278400$21.60Special order, ships in 7-14 days
485833900Ferrari Screw M5 x 16 TBFTX - 85833900$0.65Available, ships in 3-6 days
5835458Ferrari Raymond Clip - 835458$0.82Special order, ships in 7-14 days
816083501Ferrari Trim Screw 4x12 - 16083501$0.12Available, ships in 3-6 days
9231620Ferrari/Maserati Screw - 231620$0.58In stock
1012647624Ferrari Washer D 6.45-16x2 - 12647624$0.19Available, ships in 3-6 days
11914131Ferrari Screw - 914131$1.11Special order, ships in 7-14 days
12898133Ferrari Allen Head Bolt M10X1.25X 75 Esloc - 898133$13.53Special order, ships in 7-14 days
13827520Ferrari Dashboard Mounting Spacer - 827520$2.59Special order, ships in 7-14 days
1485692300Ferrari Screw M5 x 20 TBFTX - 85692300$0.65Available, ships in 3-6 days
1512638178Ferrari Washer 5.45-14x1 - 12638178$0.13Available, ships in 3-6 days
1612638124Ferrari Washer - 12638124$0.08Available, ships in 3-6 days
1612638101Ferrari Washer White - 12638101SupersededOrder 12638124 instead
1714418131Ferrari Screw M3 x 10 TCEI - 14418131$0.38Available, ships in 3-6 days
1884761600Ferrari Clip - 84761600$0.79Special order, ships in 7-14 days
1965377400Ferrari Screw M6 x 1 x 18 - 65377400$3.91Available, ships in 3-6 days
2082535800Ferrari Press Fastener Pin - 82535800$3.03Available, ships in 3-6 days
2116101777Ferrari Nut - 16101777$0.31Available, ships in 3-6 days
2213270417Ferrari Screw 3x8 - 13270417$0.13Special order, ships in 7-14 days
2316083401Ferrari Screw - 16083401$1.17Available, ships in 3-6 days
2412643701Ferrari Flat Washer - 12643701$0.12Available, ships in 3-6 days
2564830600Ferrari Screw M6 x 22 TBEI - 64830600$3.26Available, ships in 3-6 days
2685833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
2611566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
2712624178Ferrari Washer D. 5.45 - 22 x 2 - 12624178$0.71Available, ships in 3-6 days
2813272011Ferrari Screw 4x12 - 13272011$0.44Available, ships in 3-6 days
2910523424Ferrari Washer D 6.15-18x2 - 10523424$0.92Available, ships in 3-6 days
3010902028Ferrari Screw M6 x 12 - 10902028$0.96Available, ships in 3-6 days
3165752800Ferrari Screw M4 x 10 TBEI - 65752800$4.12Available, ships in 3-6 days
3213579001Ferrari Washer D.4.15-9X0.5 - 13579001SupersededOrder 12642821 instead
3385692000Ferrari SCREW - 85692000$0.65Available, ships in 3-6 days
34309629Ferrari Screw 4x8 - 309629$4.77Special order, ships in 7-14 days
3585599600Ferrari Snap Fastener Clip - 85599600$0.44Special order, ships in 7-14 days
3615782504Ferrari Screw 3.5x10 - 15782504$0.86Available, ships in 3-6 days
3714418074Ferrari Screw M3x8 - 14418074$0.40Available, ships in 3-6 days
3812639901Ferrari Washer - 12639901$0.17Available, ships in 3-6 days
39963365Ferrari Self-Tapping Screw D.35 x 8 - 963365$2.38Special order, ships in 7-14 days
40967402Ferrari Metal Clip 46 X 18 - 967402$6.96Special order, ships in 7-14 days
4185691900Ferrari Screw M5 x 8 TBFTX - 85691900$0.65Available, ships in 3-6 days
4212644401Ferrari Washer - 12644401$0.08Available, ships in 3-6 days
4385692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
4480365900Ferrari Screw M4 x 12 TSEI - 80365900$0.31Available, ships in 3-6 days
4516284934Ferrari Screw - 16284934$1.61Available, ships in 3-6 days
4516284927Ferrari Screw 5x10 - 16284927SupersededOrder 16284934 instead
4614305324Ferrari Screw M6 x 20mm - 14305324$0.17Available, ships in 3-6 days
4714305924Ferrari Allen Screw 6x45 - 14305924$0.38Available, ships in 3-6 days
47231624Ferrari Allen Screw M6 x 45 - 231624SupersededOrder 14305924 instead
4885441400Ferrari Plate - 85441400$10.91Special order, ships in 7-14 days
5015689201Ferrari Screw M3.5 x 25 - 15689201$1.92Available, ships in 3-6 days
5163343400Ferrari Screw 4x15 - 63343400$5.02Available, ships in 3-6 days
5115688801Ferrari Screw M3.5 x 13 - 15688801SupersededOrder 63343400 instead
5214059121Ferrari Nut M5 - 14059121$0.31Available, ships in 3-6 days
