Ferrari SF90 Spider — [VEHICLE TRIM] - E.49 - INNER TRIM (ABOVE BELTLINE) (diagram 0159)
Exploded view of the [vehicle trim] - e.49 - inner trim (above beltline) on the Ferrari SF90 Spider, with 18 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Spider [VEHICLE TRIM] - E.49 - INNER TRIM (ABOVE BELTLINE) exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-spider/0159.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 857465 | Ferrari Compl. Mirror Cover - 857465 | Superseded | Order 846652 instead | |
| 1 | 947695 | Ferrari Upper Windscreen Trim - 947695 | $2,110.49 | Special order, ships in 7-14 days |
| 2 | 879640 | Ferrari Compl. RH Windscreen Pillar - 879640 | $1,698.93 | Special order, ships in 7-14 days |
| 3 | 879639 | Ferrari Compl. LH Windscreen Pillar - 879639 | $1,649.69 | Special order, ships in 7-14 days |
| 4 | 770661 | Ferrari RH Sun Visor - 770661 | $2,248.03 | Special order, ships in 7-14 days |
| 4 | 772405 | Ferrari RH Sun Visor - 772405 | $2,248.03 | Special order, ships in 7-14 days |
| 4 | 938797 | Ferrari RH Sun Visor - 938797 | $2,248.03 | Special order, ships in 7-14 days |
| 4 | 963490 | Ferrari RH Sun Visor - 963490 | $2,154.37 | Special order, ships in 7-14 days |
| 4 | 964811 | Ferrari RH Sun Visor - 964811 | $2,248.03 | Special order, ships in 7-14 days |
| 5 | 770660 | Ferrari LH Sun Visor - 770660 | $2,248.03 | Special order, ships in 7-14 days |
| 5 | 938796 | Ferrari LH Sun Visor - 938796 | $2,248.03 | Special order, ships in 7-14 days |
| 5 | 964810 | Ferrari LH Sun Visor - 964810 | $2,271.45 | Special order, ships in 7-14 days |
| 6 | 13311677 | Ferrari Screw - 13311677 | $1.17 | Special order, ships in 7-14 days |
| 7 | 12644401 | Ferrari Washer - 12644401 | $0.08 | Available, ships in 3-6 days |
| 8 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 9 | 846652 | Ferrari Compl. Mirror Cover - 846652 | $142.79 | Special order, ships in 7-14 days |
| 10 | 818530 | Ferrari Mirror Cover Blanking Cap - 818530 | $36.92 | Special order, ships in 7-14 days |
| 11 | 912315 | Ferrari Tela Riparo Acqua Lunotto - 912315 | $110.78 | Special order, ships in 7-14 days |
