Ferrari SF90 Spider — [ELECTRICAL SYSTEM] - F.08 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM (diagram 0183)
Exploded view of the [electrical system] - f.08 - various fastenings for the electrical system on the Ferrari SF90 Spider, with 53 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Spider [ELECTRICAL SYSTEM] - F.08 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-spider/0183.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12486580 | Ferrari Botton - 12486580 | Superseded | Order 204781 instead | |
| 175871 | Ferrari Clip - 175871 | Superseded | Order 204781 instead | |
| 14569480 | Ferrari Clip 10x3.8 Black - 14569480 | $0.54 | Available, ships in 3-6 days | |
| 323365 | Ferrari Connector Fastener Clip - 323365 | Superseded | Order 204781 instead | |
| 13046011 | Ferrari Flanged Nut - 13046011 | $0.73 | Available, ships in 3-6 days | |
| 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 10615301 | Ferrari Washer - 10615301 | Superseded | Order 149951 instead | |
| 1 | 10852087 | Ferrari Moun Clip - 10852087 | $41.82 | Special order, ships in 7-14 days |
| 2 | 175119 | Ferrari Bracket With Sheath - 175119 | $11.29 | Special order, ships in 7-14 days |
| 3 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 4 | 179309 | Ferrari ADHESIVE FOAM - 179309 | $8.28 | Available, ships in 3-6 days |
| 5 | 323137 | Ferrari Bracket With Sheath - 323137 | $46.69 | Special order, ships in 7-14 days |
| 6 | 317027 | Ferrari Clip - 317027 | $1.02 | Special order, ships in 7-14 days |
| 7 | 10448890 | Ferrari Bracket With Sheath - 10448890 | $4.16 | Available, ships in 3-6 days |
| 8 | 244221 | Ferrari Clip - 244221 | $8.28 | Available, ships in 3-6 days |
| 9 | 883369 | Ferrari Fixing Bracket to Body - 883369 | $61.52 | Special order, ships in 7-14 days |
| 10 | 14059111 | Ferrari Flanged Nut M5 - 14059111 | $0.08 | Available, ships in 3-6 days |
| 11 | 85159800 | Ferrari CONNECTOR - 85159800 | $34.40 | Special order, ships in 7-14 days |
| 12 | 84487000 | Ferrari CLIP - 84487000 | $6.96 | Special order, ships in 7-14 days |
| 13 | 16297934 | Ferrari Flanged Screw M8 x 18 - 16297934 | $1.30 | Special order, ships in 7-14 days |
| 14 | 242384 | Ferrari Clip - 242384 | $0.59 | Available, ships in 3-6 days |
| 15 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 16 | 85692000 | Ferrari SCREW - 85692000 | $0.65 | Available, ships in 3-6 days |
| 17 | 291225 | Ferrari P clip Bracket With Sheath - 291225 | $7.86 | Special order, ships in 7-14 days |
| 18 | 16285127 | Ferrari Screw M5 x 16 - 16285127 | $1.05 | Special order, ships in 7-14 days |
| 19 | 291408 | Ferrari Clip - 291408 | $0.34 | Special order, ships in 7-14 days |
| 20 | 145854 | Ferrari Cable tie 200mm - 145854 | $0.57 | Available, ships in 3-6 days |
| 21 | 14059311 | Ferrari NUT - 14059311 | $0.52 | Available, ships in 3-6 days |
| 22 | 14059211 | Ferrari Flanged Nut - 14059211 | $0.13 | Available, ships in 3-6 days |
| 23 | 14040514 | Ferrari Flanged Nut - 14040514 | Superseded | Order 13046011 instead |
| 24 | 10450790 | Ferrari Clamp 22mm - 10450790 | $1.11 | Available, ships in 3-6 days |
| 24 | 10442290 | Ferrari P Clip Bracket With Sheath - 10442290 | $1.42 | Special order, ships in 7-14 days |
| 25 | 10441990 | Ferrari P Clip Bracket With Sheath - 10441990 | $1.42 | Available, ships in 3-6 days |
| 26 | 16296924 | Ferrari Screw M6 x 14 TE - 16296924 | $0.54 | Available, ships in 3-6 days |
| 27 | 16287024 | Ferrari Screw - 16287024 | $1.00 | In stock |
| 28 | 280460 | Ferrari Screw M8 x 14 TCEI with Washer - 280460 | $9.16 | Available, ships in 3-6 days |
| 29 | 256323 | Ferrari Screw 5x16 - 256323 | $0.98 | Available, ships in 3-6 days |
| 30 | 918833 | Ferrari Clip Hellermann Per Connetto - 918833 | $0.52 | Special order, ships in 7-14 days |
| 31 | 255869 | Ferrari Clip - 255869 | $3.91 | Special order, ships in 7-14 days |
| 32 | 786155 | Ferrari Clip - 786155 | $1.80 | Special order, ships in 7-14 days |
| 33 | 61712600 | Ferrari P Clip Bracket With Sheath D28 - 61712600 | $3.26 | Available, ships in 3-6 days |
| 34 | 248061 | Ferrari Clip - 248061 | $4.12 | Available, ships in 3-6 days |
| 35 | 11673111 | Ferrari Nut - 11673111 | $0.52 | Available, ships in 3-6 days |
| 35 | 14084111 | Ferrari Nut - 14084111 | Superseded | Order 11673111 instead |
| 36 | 149951 | Ferrari Shake Proof Washer - 149951 | $0.59 | Available, ships in 3-6 days |
| 37 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 38 | 920886 | Ferrari Retaining Clip - 920886 | $0.82 | Special order, ships in 7-14 days |
| 39 | 14059121 | Ferrari Nut M5 - 14059121 | $0.31 | Available, ships in 3-6 days |
| 40 | 818353 | Ferrari Shield Sleeve - 818353 | $36.92 | Special order, ships in 7-14 days |
| 42 | 963118 | Ferrari Bracket - 963118 | $56.60 | Special order, ships in 7-14 days |
| 43 | 303385 | Ferrari Clip - 303385 | $0.57 | Special order, ships in 7-14 days |
| 45 | 204781 | Ferrari Clip - 204781 | $1.67 | Available, ships in 3-6 days |
