Ferrari SF90 Stradale — [ENGINE] - B.14 - ENGINE INTAKE DUCT (diagram 0019)
Exploded view of the [engine] - b.14 - engine intake duct on the Ferrari SF90 Stradale, with 33 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Stradale [ENGINE] - B.14 - ENGINE INTAKE DUCT exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-stradale/0019.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14432221 | Ferrari Screw - 14432221 | Superseded | Order 231619 instead | |
| 14432224 | Ferrari Screw M6 x 22 - 14432224 | Superseded | Order 231619 instead | |
| 1 | 70006941 | Ferrari COMPL. RH INTAKE MANIFOLD - 70006941 | Price on request | Contact us for price and availability |
| 1 | 742025 | Ferrari Compl. RH Intake Manifold - 742025 | $18,236.67 | Special order, ships in 7-14 days |
| 1 | 822076 | Ferrari Compl. RH Intake Manifold - 822076 | $18,186.69 | Special order, ships in 7-14 days |
| 1 | 862918 | Ferrari Compl. RH Intake Manifold - 862918 | $1,829.08 | Special order, ships in 7-14 days |
| 1 | 978931 | Ferrari Compl. RH Intake Manifold - 978931 | Superseded | Order 822076 instead |
| 1 | 979065 | Ferrari Compl. RH Intake Manifold - 979065 | $18,514.76 | Special order, ships in 7-14 days |
| 1 | 871812 | Ferrari Complete RH Intake Manifold - 871812 | $1,899.43 | Special order, ships in 7-14 days |
| 1 | 70006940 | Ferrari RH INTAKE MANIFOLD - 70006940 | Price on request | Contact us for price and availability |
| 2 | 70006943 | Ferrari COMPL. LH INTAKE MANIFOLD - 70006943 | Price on request | Contact us for price and availability |
| 2 | 742026 | Ferrari Compl. LH Intake Manifold - 742026 | $18,236.67 | Special order, ships in 7-14 days |
| 2 | 822077 | Ferrari Compl. LH Intake Manifold - 822077 | $18,186.69 | Special order, ships in 7-14 days |
| 2 | 978932 | Ferrari Compl. LH Intake Manifold - 978932 | Superseded | Order 822077 instead |
| 2 | 979066 | Ferrari Compl. LH Intake Manifold - 979066 | $18,514.76 | Special order, ships in 7-14 days |
| 2 | 862916 | Ferrari Compl.LH Intake Manifold - 862916 | $1,829.08 | Special order, ships in 7-14 days |
| 2 | 871813 | Ferrari Complete LH Intake Manifold - 871813 | $1,899.43 | Special order, ships in 7-14 days |
| 2 | 70006942 | Ferrari LH INTAKE MANIFOLD - 70006942 | Price on request | Contact us for price and availability |
| 3 | 867178 | Ferrari Guarniz. Collettori Aspirazi - 867178 | $43.74 | Special order, ships in 7-14 days |
| 4 | 958262 | Ferrari Allen Head Bolt with Washer M6X27 - 958262 | $1.15 | Special order, ships in 7-14 days |
| 4 | 978740 | Ferrari Screw - 978740 | $3.70 | Special order, ships in 7-14 days |
| 4 | 231619 | Ferrari Screw M6 x 22 - 231619 | $0.54 | Available, ships in 3-6 days |
| 5 | 10261160 | Ferrari Washer - 10261160 | $3.26 | Available, ships in 3-6 days |
| 6 | 902581 | Ferrari Male Connector M14 x 1.5 - 902581 | $152.62 | Special order, ships in 7-14 days |
| 7 | 902148 | Ferrari Male Connector - 902148 | $36.92 | Special order, ships in 7-14 days |
| 7 | 791189 | Ferrari Threaded Plug - 791189 | $44.29 | Special order, ships in 7-14 days |
| 8 | 272880 | Ferrari Pressure and Temperature Sensor - 272880 | $61.26 | Available, ships in 3-6 days |
| 9 | 231620 | Ferrari/Maserati Screw - 231620 | $0.58 | In stock |
| 10 | 916852 | Ferrari Cosmetic Mesh - 916852 | $590.91 | Special order, ships in 7-14 days |
| 11 | 320837 | Ferrari Vite Tbei M6X12 - 320837 | Price on request | Contact us for price and availability |
| 11 | 976817 | Ferrari Vite Tbei M6X12 Inox - 976817 | $2.61 | Special order, ships in 7-14 days |
| 12 | 909966 | Ferrari Bracket - Intake Manifold - 909966 | $34.44 | Special order, ships in 7-14 days |
| 12 | 976532 | Ferrari Bracket - Intake Manifold Carbon Version - 976532 | $49.22 | Special order, ships in 7-14 days |
