Ferrari SF90 Stradale — [MECHANICAL SYSTEM] - D.25.01 - FRONT SUSPENSION - SHOCK ABSORBERS (diagram 0075)
Exploded view of the [mechanical system] - d.25.01 - front suspension - shock absorbers on the Ferrari SF90 Stradale, with 42 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Stradale [MECHANICAL SYSTEM] - D.25.01 - FRONT SUSPENSION - SHOCK ABSORBERS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-stradale/0075.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 187814 | Ferrari Hub Nut - 187814 | Superseded | Order 203780 instead | |
| 749878 | Ferrari Nut - 749878 | Superseded | Order 220378 instead | |
| 1 | 818754 | Ferrari LH Front Shock Absorber - 818754 | $10,866.77 | Special order, ships in 7-14 days |
| 1 | 902987 | Ferrari LH Front Shock Absorber - 902987 | $3,700.41 | Special order, ships in 7-14 days |
| 1 | 902989 | Ferrari LH Front Shock Absorber - 902989 | $4,607.92 | Special order, ships in 7-14 days |
| 1 | 818755 | Ferrari RH Front Shock Absorber - 818755 | $10,866.77 | Special order, ships in 7-14 days |
| 1 | 902988 | Ferrari RH Front Shock Absorber - 902988 | $3,700.41 | Special order, ships in 7-14 days |
| 1 | 902990 | Ferrari RH Front Shock Absorber - 902990 | $4,607.92 | Special order, ships in 7-14 days |
| 2 | 267936 | Ferrari Endstop Bush - 267936 | $66.45 | Available, ships in 3-6 days |
| 3 | 293648 | Ferrari Lower Spring Spacer D.78-1 - 293648 | $15.28 | Special order, ships in 7-14 days |
| 3 | 188996 | Ferrari Spring Support Pad - 188996 | $23.57 | Available, ships in 3-6 days |
| 4 | 778460 | Ferrari Front Suspension Spring - 778460 | $238.82 | Special order, ships in 7-14 days |
| 4 | 893343 | Ferrari Front Suspension Spring - 893343 | $196.96 | Special order, ships in 7-14 days |
| 4 | 893345 | Ferrari Front Suspension Spring - 893345 | $4,075.60 | Special order, ships in 7-14 days |
| 4 | 958077 | Ferrari Front Suspension Spring - 958077 | Superseded | Order 778460 instead |
| 4 | 986716 | Ferrari Front Suspension Spring - 986716 | $4,082.65 | Special order, ships in 7-14 days |
| 5 | 293621 | Ferrari Spring Support Pad - 293621 | $28.39 | Available, ships in 3-6 days |
| 5 | 293649 | Ferrari Upper Spring Spacer Rubber - 293649 | $26.20 | Special order, ships in 7-14 days |
| 6 | 340250 | Ferrari Compl. Shock Absorber Retainer Cap - 340250 | $393.38 | Special order, ships in 7-14 days |
| 7 | 248790 | Ferrari Screw M12 x 1.25 x 50 - 248790 | $7.63 | Available, ships in 3-6 days |
| 8 | 237297 | Ferrari Screw TCEI M12 x 1.25 x 8 - 237297 | $58.98 | Special order, ships in 7-14 days |
| 9 | 157630 | Ferrari Front and Rear Shock Bushing PREKOM - 157630 | $87.45 | In stock |
| 10 | 237821 | Ferrari Bushing 18x15 - 237821 | $9.16 | Available, ships in 3-6 days |
| 11 | 12646921 | Ferrari Washer - 12646921 | $0.92 | Available, ships in 3-6 days |
| 12 | 255271 | Ferrari Nut M12 x 1.25 x - 255271 | $2.59 | Available, ships in 3-6 days |
| 13 | 792154 | Ferrari Front AXLe Shaft - 792154 | Superseded | Order 892151 instead |
| 13 | 819425 | Ferrari Front Axle Shaft - 819425 | $1,551.20 | Special order, ships in 7-14 days |
| 13 | 892151 | Ferrari Front Axle Shaft - 892151 | $1,698.93 | Special order, ships in 7-14 days |
| 13 | 816510 | Ferrari Front Axle Shaft Damper 630 - 816510 | Superseded | Order 892151 instead |
| 14 | 966201 | Ferrari Locking Plates - Front Axle - 966201 | $66.45 | Special order, ships in 7-14 days |
| 15 | 814265 | Ferrari Screw M8 x 46.5 - 814265 | Superseded | Order 818339 instead |
| 15 | 818339 | Ferrari Screw TCEI M8x46.5 with Threadlocker - 818339 | $3.91 | Special order, ships in 7-14 days |
| 16 | 818380 | Ferrari Ralla Speciale Per Semiasse - 818380 | Superseded | Order 939890 instead |
| 16 | 939890 | Ferrari Special Ring Bearing for Axle - 939890 | $29.52 | Special order, ships in 7-14 days |
| 17 | 203780 | Ferrari/Maserati Hub Nut - 203780 | $30.05 | In stock |
| 18 | 220377 | Ferrari Washer D.12.1 - 24 X 3 - 220377 | $14.84 | Special order, ships in 7-14 days |
| 19 | 220383 | Ferrari Bush - 220383 | $66.35 | Available, ships in 3-6 days |
| 20 | 220378 | Ferrari Nut M12 - 220378 | $9.16 | Special order, ships in 7-14 days |
| 21 | 790604 | Ferrari Attuatore Cpl - 790604 | $1,914.99 | Special order, ships in 7-14 days |
| 22 | 259638 | Ferrari Gasket 8.7-14 - 259638 | $21.60 | Special order, ships in 7-14 days |
| 23 | 277168 | Ferrari Actuator Pipe - 277168 | $240.94 | Special order, ships in 7-14 days |
| 24 | 261587 | Ferrari Union - 261587 | $49.14 | Special order, ships in 7-14 days |
