Ferrari SF90 Stradale — [MECHANICAL SYSTEM] - D.38 - TOOLS PROVIDED WITH VEHICLE (diagram 0093)
Exploded view of the [mechanical system] - d.38 - tools provided with vehicle on the Ferrari SF90 Stradale, with 25 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Stradale [MECHANICAL SYSTEM] - D.38 - TOOLS PROVIDED WITH VEHICLE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-stradale/0093.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 889345 | Ferrari Compl. Toolkit Bag - 889345 | $1,107.99 | Special order, ships in 7-14 days |
| 1 | 964869 | Ferrari Compl. Toolkit Bag - 964869 | Superseded | Order 889345 instead |
| 2 | 866838 | Ferrari Chiave Sblocco Park.Lock Cam - 866838 | Superseded | Order 885828 instead |
| 2 | 885828 | Ferrari DCT Gearbox Park Lock Release Tool - 885828 | $319.62 | Special order, ships in 7-14 days |
| 3 | 178659 | Ferrari Fuse Pliers - 178659 | $4.89 | Special order, ships in 7-14 days |
| 4 | 959255 | Ferrari Gancio Di Traino Anterior - 959255 | $147.51 | Special order, ships in 7-14 days |
| 5 | 225020 | Ferrari Screwdriver - 225020 | $56.52 | Special order, ships in 7-14 days |
| 6 | 260763 | Ferrari Emergency Refuelling Funnel - 260763 | $61.99 | Available, ships in 3-6 days |
| 7 | 923985 | Ferrari Targh. Restrizione Sblocco - 923985 | $66.35 | Special order, ships in 7-14 days |
| 8 | 170093 | Ferrari Maxi Fuse 30A - 170093 | $28.39 | Available, ships in 3-6 days |
| 9 | 166835 | Ferrari Maxi Fuse 40A - 166835 | $17.46 | Available, ships in 3-6 days |
| 10 | 170061 | Ferrari Maxi Fuse 50A - 170061 | $8.05 | Available, ships in 3-6 days |
| 11 | 172876 | Ferrari Mini Fuse 7.5A - 172876 | $17.02 | Available, ships in 3-6 days |
| 12 | 172877 | Ferrari Mini Fuse 10A - 172877 | $17.23 | Available, ships in 3-6 days |
| 13 | 172878 | Ferrari Mini Fuse 15Amp - 172878 | $12.00 | Available, ships in 3-6 days |
| 14 | 172879 | Ferrari Mini Fuse 20A - 172879 | $13.95 | Available, ships in 3-6 days |
| 15 | 172880 | Ferrari Mini Fuse 25Amp - 172880 | $13.95 | Available, ships in 3-6 days |
| 16 | 172881 | Ferrari Mini Fuse 30Amp - 172881 | $17.02 | Available, ships in 3-6 days |
| 17 | 11323490 | Ferrari Fusibile Jcase Lp 30A - 11323490 | $39.31 | Special order, ships in 7-14 days |
| 18 | 11323590 | Ferrari Fusibile Jcase Lp 40A - 11323590 | $39.31 | Special order, ships in 7-14 days |
| 19 | 11323690 | Ferrari Fusibile Jcase Lp 50A - 11323690 | $56.52 | Special order, ships in 7-14 days |
| 20 | 65253300 | Ferrari White Gloves - 65253300 | $49.28 | In stock |
| 21 | 873614 | Ferrari Tyre Repair Kit Holder - 873614 | $21.85 | Special order, ships in 7-14 days |
| 22 | 873613 | Ferrari Cpl Kit Fix And Go Riparago - 873613 | $565.49 | Special order, ships in 7-14 days |
| 23 | 322481 | Ferrari Repair Kit Refill Bottle - 322481 | $204.05 | Available, ships in 3-6 days |
