Ferrari SF90 Stradale — [VEHICLE TRIM] - E.18 - REAR WHEELHOUSE (diagram 0117)

Exploded view of the [vehicle trim] - e.18 - rear wheelhouse on the Ferrari SF90 Stradale, with 14 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari SF90 Stradale [VEHICLE TRIM] - E.18 - REAR WHEELHOUSE exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
881061Ferrari Screw M6x18 with Washer - 881061SupersededOrder 936581 instead
1849833Ferrari Passaruota Post.Dx Cpl - 849833$656.57Special order, ships in 7-14 days
2849829Ferrari Passaruota Post.Sx Cpl - 849829$656.57Special order, ships in 7-14 days
3913420Ferrari Compl. RH Gravel Guard - 913420$306.38Special order, ships in 7-14 days
3849842Ferrari Parasassi Dx Cpl - 849842$262.62Special order, ships in 7-14 days
4913419Ferrari Compl. LH Gravel Guard - 913419$262.62Special order, ships in 7-14 days
4849839Ferrari Parasassi Sx Cpl - 849839$172.88Special order, ships in 7-14 days
5849848Ferrari Tappo Chiusura Parafango Pos - 849848$103.38Special order, ships in 7-14 days
6849846Ferrari Tappo Chiusura Parafango Pos - 849846$103.38Special order, ships in 7-14 days
7849836Ferrari Sportello Su Passaruota Post - 849836$20.55Special order, ships in 7-14 days
8849831Ferrari Sportello Su Passaruota Post - 849831$20.55Special order, ships in 7-14 days
9936581Ferrari M6x18 Screw With Captive Washer - 936581$1.34Special order, ships in 7-14 days
1083222200Ferrari Fastener Button - 83222200$1.42Available, ships in 3-6 days
1187546600Ferrari Clip - 87546600$1.74Available, ships in 3-6 days
