Ferrari SF90 Stradale — [VEHICLE TRIM] - E.33 - FRONT LID TRIM (diagram 0134)
Exploded view of the [vehicle trim] - e.33 - front lid trim on the Ferrari SF90 Stradale, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 Stradale [VEHICLE TRIM] - E.33 - FRONT LID TRIM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-stradale/0134.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 779453 | Ferrari Mostrina Cofano Baule - 779453 | $13,129.71 | Contact us to order |
| 1 | 873570 | Ferrari Mostrina Cofano Baule - 873570 | Superseded | Order 779453 instead |
| 2 | 864798 | Ferrari Rete Cofano Baule - 864798 | $1,072.43 | Special order, ships in 7-14 days |
| 3 | 804612 | Ferrari Screw - 804612 | $1.25 | Special order, ships in 7-14 days |
| 3 | 86705000 | Ferrari Screw M5x10 TBFTX - 86705000 | $1.36 | Special order, ships in 7-14 days |
| 4 | 12642878 | Ferrari Washer - 12642878 | $0.19 | Available, ships in 3-6 days |
| 5 | 927203 | Ferrari Nut M4 x 6 Inox - 927203 | $0.44 | Special order, ships in 7-14 days |
| 6 | 82139200 | Ferrari Striker Plate - 82139200 | $66.35 | Special order, ships in 7-14 days |
| 7 | 14054577 | Ferrari Domed Nut - 14054577 | $0.59 | Available, ships in 3-6 days |
| 8 | 87294800 | Ferrari Spacer - 87294800 | $1.36 | Special order, ships in 7-14 days |
| 9 | 808847 | Ferrari Washer - 808847 | $6.32 | Special order, ships in 7-14 days |
| 10 | 84827800 | Ferrari Lid Striker Plate Film - 84827800 | $16.81 | Special order, ships in 7-14 days |
