Ferrari SF90 Stradale — [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS (diagram 0157)

Exploded view of the [vehicle trim] - e.47.09 - dashboard - fasteners on the Ferrari SF90 Stradale, with 53 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari SF90 Stradale [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
12638108Ferrari Washer - 12638108SupersededOrder 12638178 instead
12638177Ferrari Washer - 12638177SupersededOrder 12638178 instead
61276300Ferrari Washer - 61276300SupersededOrder 12638178 instead
13337547Ferrari Washer D.5 - 13337547SupersededOrder 12642821 instead
116083401Ferrari Screw - 16083401$1.17Available, ships in 3-6 days
115782504Ferrari Screw 3.5x10 - 15782504$0.86Available, ships in 3-6 days
285833900Ferrari Screw M5 x 16 TBFTX - 85833900$0.65Available, ships in 3-6 days
385833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
311566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
467278400Ferrari BRACKET - 67278400$21.60Special order, ships in 7-14 days
5898133Ferrari Allen Head Bolt M10X1.25X 75 Esloc - 898133$13.53Special order, ships in 7-14 days
584018500Ferrari Screw M10 x 75 - 84018500$10.02Special order, ships in 7-14 days
612626221Ferrari Washer - 12626221SupersededOrder 12626224 instead
612626224Ferrari Washer - 12626224$0.38Available, ships in 3-6 days
712643701Ferrari Flat Washer - 12643701$0.12Available, ships in 3-6 days
814305924Ferrari Allen Screw 6x45 - 14305924$0.38Available, ships in 3-6 days
8231624Ferrari Allen Screw M6 x 45 - 231624SupersededOrder 14305924 instead
914305324Ferrari Screw M6 x 20mm - 14305324$0.17Available, ships in 3-6 days
1013272011Ferrari Screw 4x12 - 13272011$0.44Available, ships in 3-6 days
1112644401Ferrari Washer - 12644401$0.08Available, ships in 3-6 days
1284761600Ferrari Clip - 84761600$0.79Special order, ships in 7-14 days
1381045300Ferrari Screw 6x16 - 81045300$1.36Special order, ships in 7-14 days
1485692000Ferrari SCREW - 85692000$0.65Available, ships in 3-6 days
1582535800Ferrari Press Fastener Pin - 82535800$3.03Available, ships in 3-6 days
1685692300Ferrari Screw M5 x 20 TBFTX - 85692300$0.65Available, ships in 3-6 days
1785691900Ferrari Screw M5 x 8 TBFTX - 85691900$0.65Available, ships in 3-6 days
1885692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
1968700200Ferrari Fixing Clip - 68700200$10.68Special order, ships in 7-14 days
20827520Ferrari Dashboard Mounting Spacer - 827520$2.59Special order, ships in 7-14 days
2212638178Ferrari Washer 5.45-14x1 - 12638178$0.13Available, ships in 3-6 days
2313270417Ferrari Screw 3x8 - 13270417$0.13Special order, ships in 7-14 days
2412647624Ferrari Washer D 6.45-16x2 - 12647624$0.19Available, ships in 3-6 days
2512639901Ferrari Washer - 12639901$0.17Available, ships in 3-6 days
2514498501Ferrari Washer D. 3.70-11 x 1 - 14498501$0.52Available, ships in 3-6 days
2513579001Ferrari Washer D.4.15-9X0.5 - 13579001SupersededOrder 12642821 instead
2665752800Ferrari Screw M4 x 10 TBEI - 65752800$4.12Available, ships in 3-6 days
2716101777Ferrari Nut - 16101777$0.31Available, ships in 3-6 days
2814059121Ferrari Nut M5 - 14059121$0.31Available, ships in 3-6 days
2916284934Ferrari Screw - 16284934$1.61Available, ships in 3-6 days
2916284927Ferrari Screw 5x10 - 16284927SupersededOrder 16284934 instead
3010523424Ferrari Washer D 6.15-18x2 - 10523424$0.92Available, ships in 3-6 days
3110902028Ferrari Screw M6 x 12 - 10902028$0.96Available, ships in 3-6 days
3212624178Ferrari Washer D. 5.45 - 22 x 2 - 12624178$0.71Available, ships in 3-6 days
3364830600Ferrari Screw M6 x 22 TBEI - 64830600$3.26Available, ships in 3-6 days
3416083501Ferrari Trim Screw 4x12 - 16083501$0.12Available, ships in 3-6 days
3565377400Ferrari Screw M6 x 1 x 18 - 65377400$3.91Available, ships in 3-6 days
37835458Ferrari Raymond Clip - 835458$0.82Special order, ships in 7-14 days
3912638124Ferrari Washer - 12638124$0.08Available, ships in 3-6 days
3912638101Ferrari Washer White - 12638101SupersededOrder 12638124 instead
40914131Ferrari Screw - 914131$1.11Special order, ships in 7-14 days
42898398Ferrari Screw - 898398$11.77Special order, ships in 7-14 days
