Ferrari SF90 Stradale — [ELECTRICAL SYSTEM] - F.08 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM (diagram 0183)

Exploded view of the [electrical system] - f.08 - various fastenings for the electrical system on the Ferrari SF90 Stradale, with 58 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari SF90 Stradale [ELECTRICAL SYSTEM] - F.08 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
12486580Ferrari Botton - 12486580SupersededOrder 204781 instead
175871Ferrari Clip - 175871SupersededOrder 204781 instead
14569480Ferrari Clip 10x3.8 Black - 14569480$0.54Available, ships in 3-6 days
323365Ferrari Connector Fastener Clip - 323365SupersededOrder 204781 instead
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
14039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
12575411Ferrari Nyloc Nut M6 x 6 - 12575411SupersededOrder 12575421 instead
10442290Ferrari P Clip Bracket With Sheath - 10442290$1.42Special order, ships in 7-14 days
11566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
10615301Ferrari Washer - 10615301SupersededOrder 149951 instead
110450790Ferrari Clamp 22mm - 10450790$1.11Available, ships in 3-6 days
2175119Ferrari Bracket With Sheath - 175119$11.29Special order, ships in 7-14 days
314039511Ferrari Nut - 14039511$0.54Available, ships in 3-6 days
4179309Ferrari ADHESIVE FOAM - 179309$8.28Available, ships in 3-6 days
5323137Ferrari Bracket With Sheath - 323137$46.69Special order, ships in 7-14 days
685833900Ferrari Screw M5 x 16 TBFTX - 85833900$0.65Available, ships in 3-6 days
710448890Ferrari Bracket With Sheath - 10448890$4.16Available, ships in 3-6 days
8244221Ferrari Clip - 244221$8.28Available, ships in 3-6 days
9883369Ferrari Fixing Bracket to Body - 883369$61.52Special order, ships in 7-14 days
1014059111Ferrari Flanged Nut M5 - 14059111$0.08Available, ships in 3-6 days
1185159800Ferrari CONNECTOR - 85159800$34.40Special order, ships in 7-14 days
1284487000Ferrari CLIP - 84487000$6.96Special order, ships in 7-14 days
13860456Ferrari AIRBAG RESISTOR - 860456$295.03Special order, ships in 7-14 days
14242384Ferrari Clip - 242384$0.59Available, ships in 3-6 days
15217854Ferrari CLAMP - 217854$0.52Available, ships in 3-6 days
1685692000Ferrari SCREW - 85692000$0.65Available, ships in 3-6 days
17291225Ferrari P clip Bracket With Sheath - 291225$7.86Special order, ships in 7-14 days
1816285127Ferrari Screw M5 x 16 - 16285127$1.05Special order, ships in 7-14 days
19291408Ferrari Clip - 291408$0.34Special order, ships in 7-14 days
20145854Ferrari Cable tie 200mm - 145854$0.57Available, ships in 3-6 days
2114059311Ferrari NUT - 14059311$0.52Available, ships in 3-6 days
2214059211Ferrari Flanged Nut - 14059211$0.13Available, ships in 3-6 days
2314040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
2412575421Ferrari Nyloc Nut M6 x 6 - 12575421$0.40Available, ships in 3-6 days
24102741Ferrari/Maserati Nyloc Nut M6 - 102741$0.45In stock
2510441990Ferrari P Clip Bracket With Sheath - 10441990$1.42Available, ships in 3-6 days
2616296924Ferrari Screw M6 x 14 TE - 16296924$0.54Available, ships in 3-6 days
27280460Ferrari Screw M8 x 14 TCEI with Washer - 280460$9.16Available, ships in 3-6 days
28317027Ferrari Clip - 317027$1.02Special order, ships in 7-14 days
29255869Ferrari Clip - 255869$3.91Special order, ships in 7-14 days
30257886Ferrari Raymond Clip - 257886$1.44Special order, ships in 7-14 days
31288378Ferrari Clip - 288378$1.02Special order, ships in 7-14 days
32786155Ferrari Clip - 786155$1.80Special order, ships in 7-14 days
3361712600Ferrari P Clip Bracket With Sheath D28 - 61712600$3.26Available, ships in 3-6 days
34248061Ferrari Clip - 248061$4.12Available, ships in 3-6 days
3511673111Ferrari Nut - 11673111$0.52Available, ships in 3-6 days
3514084111Ferrari Nut - 14084111SupersededOrder 11673111 instead
36149951Ferrari Shake Proof Washer - 149951$0.59Available, ships in 3-6 days
3785833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
38920886Ferrari Retaining Clip - 920886$0.82Special order, ships in 7-14 days
3914059121Ferrari Nut M5 - 14059121$0.31Available, ships in 3-6 days
40282393Ferrari Screw 6x16 - 282393$1.48Available, ships in 3-6 days
4116287024Ferrari Screw - 16287024$1.00In stock
4216286024Ferrari SCREW - 16286024$0.38Available, ships in 3-6 days
4216285124Ferrari Screw 5x16 - 16285124SupersededOrder 16286024 instead
45818353Ferrari Shield Sleeve - 818353$36.92Special order, ships in 7-14 days
48303385Ferrari Clip - 303385$0.57Special order, ships in 7-14 days
51204781Ferrari Clip - 204781$1.67Available, ships in 3-6 days
