Ferrari SF90 XX Spider — [MECHANICAL SYSTEM] - D.12 - TANK MOUNTS (diagram 0061)
Exploded view of the [mechanical system] - d.12 - tank mounts on the Ferrari SF90 XX Spider, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Spider [MECHANICAL SYSTEM] - D.12 - TANK MOUNTS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-spider/0061.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 834281 | Ferrari Isolante Termico Serbatoio D - 834281 | Superseded | Order 823386 instead | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 1 | 823386 | Ferrari Isolante Termico Serbatoio D - 823386 | $344.69 | Special order, ships in 7-14 days |
| 2 | 895661 | Ferrari Isolante Termico Serbatoio S - 895661 | $344.69 | Special order, ships in 7-14 days |
| 3 | 67315400 | Ferrari Washer - 67315400 | $0.82 | Special order, ships in 7-14 days |
| 4 | 856766 | Ferrari Ritenuta Post Dx Serb Cpl - 856766 | $167.40 | Special order, ships in 7-14 days |
| 5 | 856765 | Ferrari Ritenuta Post Sx Serb Cpl - 856765 | $167.40 | Special order, ships in 7-14 days |
| 6 | 14040614 | Ferrari Flanged Nut 6mm - 14040614 | $0.27 | Available, ships in 3-6 days |
| 7 | 16286124 | Ferrari Screw M6x20 - 16286124 | $0.71 | Special order, ships in 7-14 days |
| 8 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 9 | 14447078 | Ferrari Washer D. 5.5 - 15 x 1 - 14447078 | $0.54 | Special order, ships in 7-14 days |
| 10 | 856767 | Ferrari Lower Tank Retainer - 856767 | $142.79 | Special order, ships in 7-14 days |
| 11 | 792394 | Ferrari Screw TE M6 x 18 - 792394 | $0.84 | Available, ships in 3-6 days |
