Ferrari SF90 XX Spider — [MECHANICAL SYSTEM] - D.25.01 - FRONT SUSPENSION - SHOCK ABSORBERS (diagram 0075)
Exploded view of the [mechanical system] - d.25.01 - front suspension - shock absorbers on the Ferrari SF90 XX Spider, with 34 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Spider [MECHANICAL SYSTEM] - D.25.01 - FRONT SUSPENSION - SHOCK ABSORBERS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-spider/0075.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 902989 | Ferrari LH Front Shock Absorber - 902989 | $4,607.92 | Special order, ships in 7-14 days |
| 1 | 902990 | Ferrari RH Front Shock Absorber - 902990 | $4,607.92 | Special order, ships in 7-14 days |
| 1 | 989988 | Ferrari LH FRONT SHOCK ABSORBER - 989988 | Price on request | Contact us for price and availability |
| 1 | 989990 | Ferrari RH FRONT SHOCK ABSORBER - 989990 | Price on request | Contact us for price and availability |
| 2 | 188996 | Ferrari Spring Support Pad - 188996 | $23.57 | Available, ships in 3-6 days |
| 2 | 293648 | Ferrari Lower Spring Spacer D.78-1 - 293648 | $15.28 | Special order, ships in 7-14 days |
| 3 | 281221 | Ferrari Endstop Bush - 281221 | $61.45 | Special order, ships in 7-14 days |
| 4 | 986783 | Ferrari Front Suspension Spring - 986783 | $8,177.05 | Special order, ships in 7-14 days |
| 4 | 979732 | Ferrari Front Suspension Spring - 979732 | $226.49 | Special order, ships in 7-14 days |
| 5 | 293621 | Ferrari Spring Support Pad - 293621 | $28.39 | Available, ships in 3-6 days |
| 5 | 293649 | Ferrari Upper Spring Spacer Rubber - 293649 | $26.20 | Special order, ships in 7-14 days |
| 11 | 157630 | Ferrari Front and Rear Shock Bushing PREKOM - 157630 | $87.45 | In stock |
| 187814 | Ferrari Hub Nut - 187814 | Superseded | Order 203780 instead | |
| 749878 | Ferrari Nut - 749878 | Superseded | Order 220378 instead | |
| 818380 | Ferrari Ralla Speciale Per Semiasse - 818380 | Superseded | Order 939890 instead | |
| 814265 | Ferrari Screw M8 x 46.5 - 814265 | Superseded | Order 818339 instead | |
| 6 | 220383 | Ferrari Bush - 220383 | $66.35 | Available, ships in 3-6 days |
| 7 | 220377 | Ferrari Washer D.12.1 - 24 X 3 - 220377 | $14.84 | Special order, ships in 7-14 days |
| 8 | 220378 | Ferrari Nut M12 - 220378 | $9.16 | Special order, ships in 7-14 days |
| 9 | 340250 | Ferrari Compl. Shock Absorber Retainer Cap - 340250 | $393.38 | Special order, ships in 7-14 days |
| 10 | 237297 | Ferrari Screw TCEI M12 x 1.25 x 8 - 237297 | $58.98 | Special order, ships in 7-14 days |
| 12 | 203780 | Ferrari/Maserati Hub Nut - 203780 | $30.05 | In stock |
| 13 | 12646921 | Ferrari Washer - 12646921 | $0.92 | Available, ships in 3-6 days |
| 14 | 255271 | Ferrari Nut M12 x 1.25 x - 255271 | $2.59 | Available, ships in 3-6 days |
| 15 | 819425 | Ferrari Front Axle Shaft - 819425 | $1,551.20 | Special order, ships in 7-14 days |
| 16 | 818339 | Ferrari Screw TCEI M8x46.5 with Threadlocker - 818339 | $3.91 | Special order, ships in 7-14 days |
| 17 | 966201 | Ferrari Locking Plates - Front Axle - 966201 | $66.45 | Special order, ships in 7-14 days |
| 18 | 939890 | Ferrari Special Ring Bearing for Axle - 939890 | $29.52 | Special order, ships in 7-14 days |
| 19 | 237821 | Ferrari Bushing 18x15 - 237821 | $9.16 | Available, ships in 3-6 days |
| 20 | 790604 | Ferrari Attuatore Cpl - 790604 | $1,914.99 | Special order, ships in 7-14 days |
| 21 | 277168 | Ferrari Actuator Pipe - 277168 | $240.94 | Special order, ships in 7-14 days |
| 22 | 261587 | Ferrari Union - 261587 | $49.14 | Special order, ships in 7-14 days |
| 23 | 259638 | Ferrari Gasket 8.7-14 - 259638 | $21.60 | Special order, ships in 7-14 days |
| 24 | 248790 | Ferrari Screw M12 x 1.25 x 50 - 248790 | $7.63 | Available, ships in 3-6 days |
