Ferrari SF90 XX Spider — [VEHICLE TRIM] - E.21 - LUGGAGE COMPARTMENT INSULATION (diagram 0120)
Exploded view of the [vehicle trim] - e.21 - luggage compartment insulation on the Ferrari SF90 XX Spider, with 8 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Spider [VEHICLE TRIM] - E.21 - LUGGAGE COMPARTMENT INSULATION exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-spider/0120.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 899025 | Ferrari Front Firewall Insulation - 899025 | $344.69 | Special order, ships in 7-14 days |
| 1 | 849790 | Ferrari Isolamento Parafiamma Anteri - 849790 | $295.43 | Special order, ships in 7-14 days |
| 2 | 67315400 | Ferrari Washer - 67315400 | $0.82 | Special order, ships in 7-14 days |
| 3 | 85692000 | Ferrari SCREW - 85692000 | $0.65 | Available, ships in 3-6 days |
| 4 | 13577724 | Ferrari Washer - 13577724 | $3.68 | Special order, ships in 7-14 days |
| 5 | 849789 | Ferrari Tampone Post. Parafango Ant. - 849789 | $71.38 | Special order, ships in 7-14 days |
| 6 | 849788 | Ferrari Tampone Post. Parafango Ant. - 849788 | $71.38 | Special order, ships in 7-14 days |
| 7 | 67640300 | Ferrari Fixing Button - 67640300 | $1.04 | Available, ships in 3-6 days |
