Ferrari SF90 XX Spider — [VEHICLE TRIM] - E.22 - FRONT AIR INTAKES (diagram 0121)
Exploded view of the [vehicle trim] - e.22 - front air intakes on the Ferrari SF90 XX Spider, with 17 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Spider [VEHICLE TRIM] - E.22 - FRONT AIR INTAKES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-spider/0121.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12638108 | Ferrari Washer - 12638108 | Superseded | Order 12638178 instead | |
| 12638177 | Ferrari Washer - 12638177 | Superseded | Order 12638178 instead | |
| 61276300 | Ferrari Washer - 61276300 | Superseded | Order 12638178 instead | |
| 1 | 946217 | Ferrari RH Front Duct - 946217 | $467.80 | Special order, ships in 7-14 days |
| 2 | 946195 | Ferrari LH Front Duct - 946195 | $467.80 | Special order, ships in 7-14 days |
| 3 | 945250 | Ferrari Compl. RH Brake Air Duct - 945250 | $492.43 | Special order, ships in 7-14 days |
| 4 | 945239 | Ferrari Compl. LH Brake Air Duct - 945239 | $492.43 | Special order, ships in 7-14 days |
| 5 | 920406 | Ferrari Compl. RH S-Duct - 920406 | $615.54 | Special order, ships in 7-14 days |
| 6 | 920141 | Ferrari Compl. LH S-Duct - 920141 | $615.54 | Special order, ships in 7-14 days |
| 7 | 918451 | Ferrari SCREW - 918451 | $1.53 | Special order, ships in 7-14 days |
| 8 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 9 | 907300 | Ferrari Screw M5 x 14 TBFTX Nerinox - 907300 | $0.98 | Special order, ships in 7-14 days |
| 10 | 12638178 | Ferrari Washer 5.45-14x1 - 12638178 | $0.13 | Available, ships in 3-6 days |
| 11 | 920418 | Ferrari Compl. Upper Mt Duct - 920418 | $1,625.07 | Special order, ships in 7-14 days |
| 12 | 946925 | Ferrari Compl. Inlet Duct - 946925 | $590.91 | Special order, ships in 7-14 days |
| 13 | 766266 | Ferrari Screw M5 x 14 - 766266 | $1.17 | Special order, ships in 7-14 days |
| 14 | 11566524 | Ferrari Screw M5X20 - 11566524 | $0.98 | Available, ships in 3-6 days |
