Ferrari SF90 XX Spider — [ELECTRICAL SYSTEM] - F.18 - ELECTRIC AXLE COOLING (diagram 0193)
Exploded view of the [electrical system] - f.18 - electric axle cooling on the Ferrari SF90 XX Spider, with 31 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Spider [ELECTRICAL SYSTEM] - F.18 - ELECTRIC AXLE COOLING exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-spider/0193.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 206536 | Ferrari Clip D.14 - 206536 | $0.92 | Special order, ships in 7-14 days | |
| 862859 | Ferrari LH Bracket - Vent Pipe for Axle Cooling - 862859 | Superseded | Order 766349 instead | |
| 904921 | Ferrari Pompa Con Piastra Cpl. - 904921 | Superseded | Order 894450 instead | |
| 968766 | Ferrari Pompa Con Piastra Cpl. - 968766 | Superseded | Order 894450 instead | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 1 | 894450 | Ferrari Pompa Con Piastra Cpl. - 894450 | $4,319.49 | Special order, ships in 7-14 days |
| 2 | 898510 | Ferrari Pump Mounting Bracket - 898510 | $118.16 | Special order, ships in 7-14 days |
| 3 | 231622 | Ferrari Screw M6 x 35 - 231622 | $0.65 | Available, ships in 3-6 days |
| 4 | 256323 | Ferrari Screw 5x16 - 256323 | $0.98 | Available, ships in 3-6 days |
| 5 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 6 | 898513 | Ferrari Oil Delivery Pipe From Pump - 898513 | $443.17 | Special order, ships in 7-14 days |
| 7 | 286421 | Ferrari Gasket - 286421 | $1.88 | Available, ships in 3-6 days |
| 8 | 898515 | Ferrari Straight Pipe - 898515 | $344.69 | Special order, ships in 7-14 days |
| 9 | 898512 | Ferrari Oil Suction Pipe From AXLe T - 898512 | $738.64 | Special order, ships in 7-14 days |
| 10 | 898517 | Ferrari Oil Return Pipe From Radiato - 898517 | $1,157.24 | Special order, ships in 7-14 days |
| 11 | 883407 | Ferrari Bracket - 883407 | $66.45 | Special order, ships in 7-14 days |
| 12 | 233600 | Ferrari/Maserati Screw - 233600 | $1.98 | In stock |
| 13 | 10441990 | Ferrari P Clip Bracket With Sheath - 10441990 | $1.42 | Available, ships in 3-6 days |
| 14 | 14040614 | Ferrari Flanged Nut 6mm - 14040614 | $0.27 | Available, ships in 3-6 days |
| 15 | 955410 | Ferrari Oil Filler Pipe - 955410 | $615.54 | Special order, ships in 7-14 days |
| 16 | 14325140 | Ferrari Threaded Plug - 14325140 | $3.70 | Available, ships in 3-6 days |
| 17 | 335820 | Ferrari Dct Vent Pipe - 335820 | $492.43 | Special order, ships in 7-14 days |
| 18 | 773829 | Ferrari Dct Expansion Tank - 773829 | $120.62 | Special order, ships in 7-14 days |
| 19 | 301886 | Ferrari Tank Breather Mount - 301886 | $172.10 | Special order, ships in 7-14 days |
| 20 | 85629300 | Ferrari Screw M6 x 20 - 85629300 | $1.17 | Available, ships in 3-6 days |
| 21 | 13434670 | Ferrari Screw Collar D16.2mm - 13434670 | $1.44 | Available, ships in 3-6 days |
| 22 | 10284460 | Ferrari Washer - 10284460 | $0.31 | Available, ships in 3-6 days |
| 23 | 968342 | Ferrari Connector - 968342 | $167.40 | Special order, ships in 7-14 days |
| 24 | 198253 | Ferrari Clip - 198253 | $7.40 | Special order, ships in 7-14 days |
| 25 | 766349 | Ferrari LH Bracket - 766349 | $88.61 | Special order, ships in 7-14 days |
| 26 | 231627 | Ferrari Screw M8 x 16 - 231627 | $1.25 | Available, ships in 3-6 days |
