Ferrari SF90 XX Stradale — [ENGINE] - B.14 - ENGINE INTAKE DUCT (diagram 0019)
Exploded view of the [engine] - b.14 - engine intake duct on the Ferrari SF90 XX Stradale, with 35 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Stradale [ENGINE] - B.14 - ENGINE INTAKE DUCT exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-stradale/0019.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 958262 | Ferrari Allen Head Bolt with Washer M6X27 - 958262 | $1.15 | Special order, ships in 7-14 days | |
| 909966 | Ferrari Bracket - Intake Manifold - 909966 | $34.44 | Special order, ships in 7-14 days | |
| 14432221 | Ferrari Screw - 14432221 | Superseded | Order 231619 instead | |
| 14432224 | Ferrari Screw M6 x 22 - 14432224 | Superseded | Order 231619 instead | |
| 1 | 55014354 | Ferrari Compl. RH Plenum - 55014354 | $18,623.39 | Contact us to order |
| 1 | 55018885 | Ferrari Compl. RH Plenum - 55018885 | $18,623.39 | Contact us to order |
| 1 | 70008434 | Ferrari COMPL. RH PLENUM - 70008434 | Price on request | Contact us for price and availability |
| 1 | 70008435 | Ferrari COMPL. RH PLENUM - 70008435 | Price on request | Contact us for price and availability |
| 1 | 70008436 | Ferrari COMPL. RH PLENUM - 70008436 | Price on request | Contact us for price and availability |
| 1 | 70008437 | Ferrari COMPL. RH PLENUM - 70008437 | Price on request | Contact us for price and availability |
| 1 | 833860 | Ferrari Compl. RH Plenum - 833860 | $17,739.14 | Contact us to order |
| 1 | 973795 | Ferrari Compl. RH Plenum - 973795 | $18,810.23 | Contact us to order |
| 2 | 55014355 | Ferrari Compl. LH Plenum - 55014355 | $18,623.39 | Contact us to order |
| 2 | 55018886 | Ferrari Compl. LH Plenum - 55018886 | $18,623.39 | Contact us to order |
| 2 | 70008438 | Ferrari COMPL. LH PLENUM - 70008438 | Price on request | Contact us for price and availability |
| 2 | 70008439 | Ferrari COMPL. LH PLENUM - 70008439 | Price on request | Contact us for price and availability |
| 2 | 70008440 | Ferrari COMPL. LH PLENUM - 70008440 | Price on request | Contact us for price and availability |
| 2 | 70008441 | Ferrari COMPL. LH PLENUM - 70008441 | Price on request | Contact us for price and availability |
| 2 | 833868 | Ferrari Compl. LH Plenum - 833868 | $17,739.14 | Contact us to order |
| 2 | 973794 | Ferrari Compl. LH Plenum - 973794 | $18,810.23 | Contact us to order |
| 3 | 867178 | Ferrari Guarniz. Collettori Aspirazi - 867178 | $43.74 | Special order, ships in 7-14 days |
| 4 | 978740 | Ferrari Screw - 978740 | $3.70 | Special order, ships in 7-14 days |
| 5 | 10261160 | Ferrari Washer - 10261160 | $3.26 | Available, ships in 3-6 days |
| 6 | 902581 | Ferrari Male Connector M14 x 1.5 - 902581 | $152.62 | Special order, ships in 7-14 days |
| 7 | 902148 | Ferrari Male Connector - 902148 | $36.92 | Special order, ships in 7-14 days |
| 7 | 791189 | Ferrari Threaded Plug - 791189 | $44.29 | Special order, ships in 7-14 days |
| 8 | 272880 | Ferrari Pressure and Temperature Sensor - 272880 | $61.26 | Available, ships in 3-6 days |
| 9 | 231619 | Ferrari Screw M6 x 22 - 231619 | $0.54 | Available, ships in 3-6 days |
| 10 | 916852 | Ferrari Cosmetic Mesh - 916852 | $590.91 | Special order, ships in 7-14 days |
| 11 | 976817 | Ferrari Vite Tbei M6X12 Inox - 976817 | $2.61 | Special order, ships in 7-14 days |
| 12 | 976532 | Ferrari Bracket - Intake Manifold Carbon Version - 976532 | $49.22 | Special order, ships in 7-14 days |
| 13 | 202473 | Ferrari Stud Bolt - 202473 | $56.60 | Special order, ships in 7-14 days |
| 14 | 778884 | Ferrari Damping Plate - 778884 | $20.16 | Special order, ships in 7-14 days |
| 15 | 778889 | Ferrari Damping Washer - 778889 | $10.48 | Special order, ships in 7-14 days |
| 16 | 844392 | Ferrari Nut - 844392 | $14.64 | Special order, ships in 7-14 days |
