Ferrari SF90 XX Stradale — [MECHANICAL SYSTEM] - D.29 - COMPLETE WHEELS (diagram 0083)
Exploded view of the [mechanical system] - d.29 - complete wheels on the Ferrari SF90 XX Stradale, with 49 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Stradale [MECHANICAL SYSTEM] - D.29 - COMPLETE WHEELS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-stradale/0083.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 848628 | Ferrari Front Wheel 20 x 9.5J - 848628 | $17,399.97 | Special order, ships in 7-14 days | |
| 70004402 | Ferrari Kit Sostit. Sede Colonn. Cer - 70004402 | $571.13 | Special order, ships in 7-14 days | |
| 70004351 | Ferrari Kit Sostit.Parti In All. Cer - 70004351 | Superseded | Order 70005123 instead | |
| 108947 | Ferrari Push In Hub Cap - 108947 | Superseded | Order 55059092 instead | |
| 226245 | Ferrari Push In Hub Cap - 226245 | Superseded | Order 55059092 instead | |
| 1 | 915768 | Ferrari Forged LH Front Wheel - 915768 | $8,854.74 | Special order, ships in 7-14 days |
| 1 | 55026527 | Ferrari Front Wheel 20 x 9.5J - 55026527 | $18,448.62 | Special order, ships in 7-14 days |
| 1 | 764245 | Ferrari Front Wheel 20 x 9.5J - 764245 | Price on request | Contact us for price and availability |
| 1 | 70008400 | Ferrari LH Front Wheel - 70008400 | $17,728.28 | Special order, ships in 7-14 days |
| 1 | 784031 | Ferrari LH Front Wheel - 784031 | $8,237.74 | Special order, ships in 7-14 days |
| 1 | 915440 | Ferrari LH Front Wheel - 915440 | $8,537.91 | Special order, ships in 7-14 days |
| 1 | 915761 | Ferrari LH Front Wheel - 915761 | $8,854.74 | Special order, ships in 7-14 days |
| 1 | 915779 | Ferrari LH Front Wheel - 915779 | $8,854.74 | Special order, ships in 7-14 days |
| 1 | 70008402 | Ferrari LH Rear Wheel - 70008402 | $17,728.28 | Special order, ships in 7-14 days |
| 1 | 915442 | Ferrari LH Rear Wheel - 915442 | $8,829.74 | Special order, ships in 7-14 days |
| 1 | 915766 | Ferrari LH Rear Wheel - 915766 | $9,115.30 | Special order, ships in 7-14 days |
| 1 | 915770 | Ferrari LH Rear Wheel - 915770 | $9,115.30 | Special order, ships in 7-14 days |
| 1 | 915775 | Ferrari LH Rear Wheel - 915775 | $9,115.30 | Special order, ships in 7-14 days |
| 1 | 947925 | Ferrari LH Rear Wheel - 947925 | $8,542.07 | Special order, ships in 7-14 days |
| 1 | 55026528 | Ferrari Rear Wheel 20 x 11.5J - 55026528 | $18,875.41 | Special order, ships in 7-14 days |
| 1 | 764246 | Ferrari Rear Wheel 20 x 11.5J - 764246 | Superseded | Order 55026528 instead |
| 1 | 70008401 | Ferrari RH Front Wheel - 70008401 | $17,728.28 | Special order, ships in 7-14 days |
| 1 | 784032 | Ferrari RH Front Wheel - 784032 | $8,237.74 | Special order, ships in 7-14 days |
| 1 | 915441 | Ferrari RH Front Wheel - 915441 | $8,537.91 | Special order, ships in 7-14 days |
| 1 | 915764 | Ferrari RH Front Wheel - 915764 | $8,854.74 | Special order, ships in 7-14 days |
| 1 | 915769 | Ferrari RH Front Wheel - 915769 | $8,854.74 | Special order, ships in 7-14 days |
| 1 | 915785 | Ferrari RH Front Wheel - 915785 | $8,854.74 | Special order, ships in 7-14 days |
| 1 | 70008403 | Ferrari RH Rear Wheel - 70008403 | $17,728.28 | Special order, ships in 7-14 days |
| 1 | 915443 | Ferrari RH Rear Wheel - 915443 | $8,829.74 | Special order, ships in 7-14 days |
| 1 | 915767 | Ferrari RH Rear Wheel - 915767 | $9,115.30 | Special order, ships in 7-14 days |
| 1 | 915771 | Ferrari RH Rear Wheel - 915771 | $9,115.30 | Special order, ships in 7-14 days |
| 1 | 915778 | Ferrari RH Rear Wheel - 915778 | $9,115.30 | Special order, ships in 7-14 days |
| 1 | 947926 | Ferrari RH Rear Wheel - 947926 | $8,542.07 | Special order, ships in 7-14 days |
| 2 | 314818 | Ferrari Tpms Wheel Sensor Gen 3.8 - 314818 | Superseded | Order 777770 instead |
| 2 | 314821 | Ferrari Tyre Pressure Monitoring System - 314821 | Superseded | Order 777804 instead |
| 2 | 777804 | Ferrari Tyre Pressure Monitoring System - 777804 | $327.81 | Available, ships in 3-6 days |
| 2 | 777770 | Ferrari Tyre Pressure Monitoring System Wheel Sensor - 777770 | $327.81 | Available, ships in 3-6 days |
| 3 | 913102 | Ferrari Tyre Valve - 913102 | $30.57 | Available, ships in 3-6 days |
| 3 | 913104 | Ferrari Tyre Valve - 913104 | $37.13 | Special order, ships in 7-14 days |
| 4 | 854399 | Ferrari Titanium Wheel Bolts M14 Mo. - 854399 | $344.21 | Available, ships in 3-6 days |
| 4 | 206274 | Ferrari Wheel Bolt -Titanium M14x1.5x16 - 206274 | $348.38 | Available, ships in 3-6 days |
| 5 | 70008486 | Ferrari HUB CAP - 70008486 | $7,828.38 | Special order, ships in 7-14 days |
| 5 | 889561 | Ferrari Hub Cap - 889561 | $442.56 | Special order, ships in 7-14 days |
| 5 | 340066 | Ferrari Wheel Center Cap Set - 55059092/4 | Superseded | Order 55059092 instead |
| 5 | 55059092 | Ferrari Wheel Centre Cap - 55059092 | $44.11 | Available, ships in 3-6 days |
| 6 | 11096693 | Ferrari Adhesive Wheel Balancer Weight - 11096693 | $24.32 | Special order, ships in 7-14 days |
| 6 | 308296 | Ferrari Adhesive Wheel Balancer Weight - 308296 | $24.32 | Special order, ships in 7-14 days |
| 8 | 70005123 | Ferrari Kit Sostit.Parti In All. Cer - 70005123 | $2,393.73 | Special order, ships in 7-14 days |
| 9 | 70005124 | Ferrari Kit Sostit. Sede Colonn. Cer - 70005124 | $573.70 | Special order, ships in 7-14 days |
