Ferrari SF90 XX Stradale — [VEHICLE TRIM] - E.02 - LATERAL OUTER BODYSHELL (diagram 0098)

Exploded view of the [vehicle trim] - e.02 - lateral outer bodyshell on the Ferrari SF90 XX Stradale, with 47 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari SF90 XX Stradale [VEHICLE TRIM] - E.02 - LATERAL OUTER BODYSHELL exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
87583800Ferrari Adjuster Shim 1.0mm - 87583800$3.68Special order, ships in 7-14 days
852261Ferrari Adjustment Spacer 1Mm - 852261SupersededOrder 788178 instead
87583700Ferrari Fork Adjuster Shim - 87583700$3.91Special order, ships in 7-14 days
80415900Ferrari Screw - 80415900$32.60Available, ships in 3-6 days
12643711Ferrari Washer - 12643711SupersededOrder 12643724 instead
12643721Ferrari Washer - 12643721SupersededOrder 12643724 instead
14499301Ferrari Washer - 14499301SupersededOrder 12643724 instead
1985868479Ferrari RH Flank - 985868479$54,034.37Contact us to order
2985868406Ferrari LH Flank - 985868406$54,034.37Contact us to order
3985912684Ferrari Compl. RH Front Fender - 985912684$14,038.80Contact us to order
3985941441Ferrari Compl. RH Front Fender - 985941441$13,882.45Contact us to order
4985911823Ferrari Compl. LH Front Fender - 985911823$14,038.80Contact us to order
4985941438Ferrari Compl. LH Front Fender - 985941438$13,882.45Contact us to order
5985899979Ferrari RH Fixed Spoiler - 985899979$3,494.05Special order, ships in 7-14 days
6985899943Ferrari LH Fixed Spoiler - 985899943$3,494.05Special order, ships in 7-14 days
7944443Ferrari VARIABLE GEOM. SPOILER - 944443Price on requestContact us for price and availability
7983033Ferrari VARIABLE GEOM. SPOILER - 983033Price on requestContact us for price and availability
8921749Ferrari Spess.Con Piego Di Regol.A F - 921749$15.74Special order, ships in 7-14 days
8921750Ferrari Spess.Con Piego Di Regol.A F - 921750$14.26Special order, ships in 7-14 days
9837486Ferrari Rivet - 837486$14.64Special order, ships in 7-14 days
1012647724Ferrari Washer - 12647724$0.31Available, ships in 3-6 days
1113046114Ferrari Flanged Nut - 13046114$0.31Available, ships in 3-6 days
12900885Ferrari Adjustment Shim - 900885SupersededOrder 87583800 instead
12900889Ferrari Adjustment Shim - 900889SupersededOrder 87583700 instead
1316286224Ferrari Screw M6x25 - 16286224$4.77Special order, ships in 7-14 days
14921747Ferrari Spess.Curvo Di Regolaz.A For - 921747SupersededOrder 87583800 instead
14921748Ferrari Spess.Curvo Di Regolaz.A For - 921748$12.29Special order, ships in 7-14 days
15877434Ferrari Rivet - 877434$19.66Special order, ships in 7-14 days
16985830981Ferrari Rinforzo Nodo H Int Dx Cpl C - 985830981$443.17Special order, ships in 7-14 days
16985830977Ferrari Rinforzo Nodo H Int Sx Cpl C - 985830977$443.17Special order, ships in 7-14 days
1716286121Ferrari Screw M6 x 20 - 16286121$1.23Available, ships in 3-6 days
1812643724Ferrari/Maserati Washer - 12643724$0.20In stock
1981126600Ferrari Rivet D.3.9X7 - 81126600$0.71Available, ships in 3-6 days
2014639791Ferrari Rivet D. 6.4X 14.1 - 14639791$2.59Special order, ships in 7-14 days
2181126900Ferrari Rivet D.4.8X7.5 - 81126900$0.86Available, ships in 3-6 days
2284539300Ferrari Rivet - 84539300$1.15Special order, ships in 7-14 days
23284430Ferrari Rivet - 284430$3.91Special order, ships in 7-14 days
2414639591Ferrari Rivet - 14639591$3.03Available, ships in 3-6 days
2586847700Ferrari Fork Adjuster Shim 0.5mm - 86847700Price on requestContact us for price and availability
2586847600Ferrari Fork Adjuster Shim 1.0mm - 86847600$9.81Special order, ships in 7-14 days
26788178Ferrari Spessore Di Regolaz.Sp.1Mm - 788178$13.11Special order, ships in 7-14 days
2716287221Ferrari Screw - 16287221$0.59Available, ships in 3-6 days
2716287224Ferrari Screw M8x25 - 16287224$0.82Available, ships in 3-6 days
28875138Ferrari LH A Pillar Cover Fastener B - 875138$34.44Special order, ships in 7-14 days
28875139Ferrari RH A Pillar Cover Fastener B - 875139$34.44Special order, ships in 7-14 days
2916285127Ferrari Screw M5 x 16 - 16285127$1.05Special order, ships in 7-14 days
3081126700Ferrari Rivet D.3.9X7 - 81126700$0.65Available, ships in 3-6 days
