Ferrari SF90 XX Stradale — [VEHICLE TRIM] - E.03 - ROOF (diagram 0099)
Exploded view of the [vehicle trim] - e.03 - roof on the Ferrari SF90 XX Stradale, with 16 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Stradale [VEHICLE TRIM] - E.03 - ROOF exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-stradale/0099.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 871461 | Ferrari Rear Screen Assembly - 871461 | Superseded | Order 741154 instead | |
| 872868 | Ferrari Rear Screen Assembly - 872868 | Superseded | Order 741153 instead | |
| 1 | 985830112 | Ferrari Rivestimento Padigliglione P - 985830112 | $20,246.31 | Contact us to order |
| 2 | 985838305 | Ferrari Traversa Sup. Parabrezza Cat - 985838305 | $1,748.17 | Special order, ships in 7-14 days |
| 3 | 985838303 | Ferrari Traversa Sup. Lunotto Catafo - 985838303 | $1,304.98 | Special order, ships in 7-14 days |
| 4 | 741153 | Ferrari Rear Screen Assembly - 741153 | $17,095.13 | Contact us to order |
| 4 | 741154 | Ferrari Rear Screen Assembly - 741154 | $11,244.32 | Contact us to order |
| 4 | 743143 | Ferrari Rear Screen Assembly - 743143 | $12,752.17 | Contact us to order |
| 5 | 852496 | Ferrari Cpl Setto Dx - 852496 | $88.61 | Special order, ships in 7-14 days |
| 6 | 852495 | Ferrari Cpl Setto Sx - 852495 | $88.61 | Special order, ships in 7-14 days |
| 7 | 985573 | Ferrari Vite Tbti M8X28+Colla+R.Imp. - 985573 | $15.51 | Special order, ships in 7-14 days |
| 8 | 964589 | Ferrari Vite Tcti M6X16+Colla+R.Imp. - 964589 | $4.35 | Special order, ships in 7-14 days |
| 10 | 964587 | Ferrari Screw - 964587 | $39.37 | Special order, ships in 7-14 days |
| 11 | 917020 | Ferrari Top Tether Fastener Bracket - 917020 | $108.16 | Special order, ships in 7-14 days |
| 12 | 878133 | Ferrari Screw - 878133 | $34.94 | Special order, ships in 7-14 days |
| 13 | 14496527 | Ferrari Washer - 14496527 | $2.38 | Available, ships in 3-6 days |
