Ferrari SF90 XX Stradale — [VEHICLE TRIM] - E.18 - REAR WHEELHOUSE (diagram 0117)
Exploded view of the [vehicle trim] - e.18 - rear wheelhouse on the Ferrari SF90 XX Stradale, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Stradale [VEHICLE TRIM] - E.18 - REAR WHEELHOUSE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-stradale/0117.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 881061 | Ferrari Screw M6x18 with Washer - 881061 | Superseded | Order 936581 instead | |
| 1 | 903928 | Ferrari Compl. RH Rear WheeLHouse - 903928 | $1,291.30 | Special order, ships in 7-14 days |
| 2 | 903800 | Ferrari Compl. LH Rear WheeLHouse - 903800 | $1,291.30 | Special order, ships in 7-14 days |
| 3 | 920452 | Ferrari Compl. RH Rear Gravel Guard - 920452 | $4,904.70 | Special order, ships in 7-14 days |
| 4 | 920430 | Ferrari Compl. LH Rear Gravel Guard - 920430 | $4,842.18 | Special order, ships in 7-14 days |
| 5 | 907800 | Ferrari Cover Plate On RH Rear Wheel - 907800 | $63.44 | Special order, ships in 7-14 days |
| 6 | 905684 | Ferrari Cover Plate On LH Rear Wheel - 905684 | $63.44 | Special order, ships in 7-14 days |
| 7 | 936581 | Ferrari M6x18 Screw With Captive Washer - 936581 | $1.34 | Special order, ships in 7-14 days |
| 8 | 83222200 | Ferrari Fastener Button - 83222200 | $1.42 | Available, ships in 3-6 days |
| 9 | 986768 | Ferrari Screw - 986768 | $3.26 | Special order, ships in 7-14 days |
| 10 | 87546600 | Ferrari Clip - 87546600 | $1.74 | Available, ships in 3-6 days |
| 10 | 14189071 | Ferrari M6 x 1Screw clip - 14189071 | $1.36 | Available, ships in 3-6 days |
