Ferrari SF90 XX Stradale — [VEHICLE TRIM] - E.24 - REAR AIR INTAKES (diagram 0123)
Exploded view of the [vehicle trim] - e.24 - rear air intakes on the Ferrari SF90 XX Stradale, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Stradale [VEHICLE TRIM] - E.24 - REAR AIR INTAKES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-stradale/0123.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 1 | 895985 | Ferrari FIXED SPOILER TRIM - 895985 | $135.39 | Special order, ships in 7-14 days |
| 2 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 3 | 911975 | Ferrari Flat Washer D 5.15-15X - 911975 | $0.79 | Special order, ships in 7-14 days |
| 4 | 941365 | Ferrari Compl. RH Rear Tail Light Ai - 941365 | $145.25 | Special order, ships in 7-14 days |
| 5 | 941363 | Ferrari Compl. LH Rear Tail Light Ai - 941363 | $145.25 | Special order, ships in 7-14 days |
