Ferrari SF90 XX Stradale — [VEHICLE TRIM] - E.39 - REAR LID OPENING MECHANISM (diagram 0140)
Exploded view of the [vehicle trim] - e.39 - rear lid opening mechanism on the Ferrari SF90 XX Stradale, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari SF90 XX Stradale [VEHICLE TRIM] - E.39 - REAR LID OPENING MECHANISM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/sf90-xx-stradale/0140.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 248061 | Ferrari Clip - 248061 | $4.12 | Available, ships in 3-6 days | |
| 1 | 824874 | Ferrari Engine Compartment Lid Relea - 824874 | $514.01 | Special order, ships in 7-14 days |
| 1 | 824877 | Ferrari Engine Compartment Lid Relea - 824877 | $465.04 | Special order, ships in 7-14 days |
| 1 | 958845 | Ferrari Engine Compartment Lid Relea - 958845 | $492.43 | Special order, ships in 7-14 days |
| 2 | 13310877 | Ferrari Screw M5 x 12 TSCIC - 13310877 | $0.57 | Available, ships in 3-6 days |
| 3 | 14569480 | Ferrari Clip 10x3.8 Black - 14569480 | $0.54 | Available, ships in 3-6 days |
| 4 | 64215300 | Ferrari Door Rod Clip - 64215300 | $0.82 | Available, ships in 3-6 days |
| 5 | 14569680 | Ferrari Clip - 14569680 | $0.13 | Special order, ships in 7-14 days |
| 6 | 849815 | Ferrari Anti Vibration Damper - 849815 | $51.62 | Available, ships in 3-6 days |
| 7 | 14569880 | Ferrari Clip 14.5x3 - 14569880 | $0.65 | Special order, ships in 7-14 days |
