Ferrari 12 Cilindri Spider — [VEHICLE TRIM] - E.11 - ROLLBAR COMPARTMENT (diagram 0107)
Exploded view of the [vehicle trim] - e.11 - rollbar compartment on the Ferrari 12 Cilindri Spider, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri Spider [VEHICLE TRIM] - E.11 - ROLLBAR COMPARTMENT exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri-spider/0107.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14496609 | Ferrari Steel Washer - 14496609 | Superseded | Order 12646824 instead | |
| 14496601 | Ferrari Washer - 14496601 | Superseded | Order 12646824 instead | |
| 14496621 | Ferrari Washer - 14496621 | Superseded | Order 12646824 instead | |
| 14496624 | Ferrari Washer D. 10.50-21 x2 - 14496624 | $0.12 | Available, ships in 3-6 days | |
| 1 | 993847 | Ferrari REAR SCREEN VALENCE - 993847 | $11,804.62 | Contact us to order |
| 2 | 68984500 | Ferrari Screw TEF M10 x 1.25 x 30 - 68984500 | $5.86 | Available, ships in 3-6 days |
| 3 | 12646824 | Ferrari Washer - 12646824 | Superseded | Order 14496624 instead |
| 4 | 986910 | Ferrari Shim 0.5mm - 986910 | $6.36 | Special order, ships in 7-14 days |
| 4 | 986912 | Ferrari Shim 1.0mm - 986912 | $7.11 | Special order, ships in 7-14 days |
| 5 | 333924 | Ferrari Screw Te M10X1.25 X70 - 333924 | $34.94 | Special order, ships in 7-14 days |
