Ferrari 12 Cilindri — [MECHANICAL SYSTEM] - D.25.02 - FRONT SUSPENSION - ARMS (diagram 0076)

Exploded view of the [mechanical system] - d.25.02 - front suspension - arms on the Ferrari 12 Cilindri, with 54 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 12 Cilindri [MECHANICAL SYSTEM] - D.25.02 - FRONT SUSPENSION - ARMS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
238693Ferrari Camber Spacer 1.0mm - 238693$10.25Special order, ships in 7-14 days
238881Ferrari Camber Spacer 1.5mm - 238881$10.25Special order, ships in 7-14 days
238882Ferrari Camber Spacer 2.5mm - 238882$10.25Special order, ships in 7-14 days
238884Ferrari Camber Spacer 3.5mm - 238884$10.25Special order, ships in 7-14 days
238885Ferrari Camber Spacer 4.0mm - 238885$10.25Special order, ships in 7-14 days
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
268896Ferrari LH Front Lower Arm Complete - 268896$1,695.11Available, ships in 3-6 days
12575621Ferrari Nyloc Nut - 12575621SupersededOrder 102742 instead
320528Ferrari Potentiometer Tie-Rod - 320528$113.08Special order, ships in 7-14 days
268897Ferrari RH Front Lower Arm Complete - 268897$2,051.44Special order, ships in 7-14 days
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
126648Ferrari Washer - 126648SupersededOrder 14496624 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
1985489Ferrari Compl. LH Front Hub Carrier - 985489$3,765.47Special order, ships in 7-14 days
1985490Ferrari Compl. RH Front Hub Carrier - 985490$3,765.47Special order, ships in 7-14 days
2268894Ferrari LH Front Lower Arm Complete - 268894$1,893.26Special order, ships in 7-14 days
2268895Ferrari RH Front Lower Arm Complete - 268895$1,893.26Special order, ships in 7-14 days
3767437Ferrari Compl. LH Front Upper Arm - 767437$1,967.03Special order, ships in 7-14 days
3767438Ferrari Compl. RH Front Upper Arm - 767438$1,967.03Special order, ships in 7-14 days
412646921Ferrari Washer - 12646921$0.92Available, ships in 3-6 days
5203795Ferrari Nut M14 x 1.5 - 203795$4.56Available, ships in 3-6 days
614040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
755025987Ferrari LH Front Hub Carrier Bracket - 55025987$51.62Special order, ships in 7-14 days
755025988Ferrari RH Front Hub Carrier Bracket - 55025988$51.62Special order, ships in 7-14 days
855001113Ferrari LH Front Bracket - 55001113$125.37Special order, ships in 7-14 days
855001114Ferrari RH Front Bracket - 55001114$125.37Special order, ships in 7-14 days
9241689Ferrari Spacer - 241689$14.62Special order, ships in 7-14 days
10149807Ferrari Self-Locking Nut For Top And Bottom Ball Joints - 149807$2.13Available, ships in 3-6 days
11263032Ferrari Camber Spacer 0.5mm - 263032$24.02Available, ships in 3-6 days
11263033Ferrari Camber Spacer 1.0mm - 263033$7.19Special order, ships in 7-14 days
11263034Ferrari Camber Spacer 1.5mm - 263034$7.19Special order, ships in 7-14 days
11238694Ferrari Camber Spacer 2.0mm - 238694SupersededOrder 263035 instead
11263035Ferrari Camber Spacer 2.0mm - 263035$7.19Available, ships in 3-6 days
11263036Ferrari Camber Spacer 2.5mm - 263036$10.25Special order, ships in 7-14 days
11263037Ferrari Camber Spacer 3.0mm - 263037SupersededOrder 238883 instead
11263038Ferrari Camber Spacer 3.5mm - 263038$10.25Special order, ships in 7-14 days
11263039Ferrari Camber Spacer 4.0mm - 263039$10.25Special order, ships in 7-14 days
12264528Ferrari Threaded Rod 10x1.25 - 264528$7.63Available, ships in 3-6 days
1314496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
14104114Ferrari Nyloc Nut M10 x 1.25 x 12 - 104114$0.73Available, ships in 3-6 days
1512646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
1512646821Ferrari Washer D.10 20-25x2 - 12646821$0.19Available, ships in 3-6 days
16749586Ferrari LH Front Bracket - 749586$63.90Special order, ships in 7-14 days
16749623Ferrari RH Front Bracket - 749623$63.90Special order, ships in 7-14 days
17231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
18934265Ferrari Compl. Travel Sensor - 934265$349.68Special order, ships in 7-14 days
19216973Ferrari Ball Joint D8 M6x1 - 216973$6.54Available, ships in 3-6 days
20340273Ferrari Ball Joint - 340273$88.49Special order, ships in 7-14 days
21984041Ferrari Potentiometer Tie-Rod - 984041$194.22Special order, ships in 7-14 days
2216284934Ferrari Screw - 16284934$1.61Available, ships in 3-6 days
2216284927Ferrari Screw 5x10 - 16284927SupersededOrder 16284934 instead
23338963Ferrari ABS Sensor - Front - 338963$128.92Available, ships in 3-6 days

All 12 Cilindri diagrams
