Ferrari 365 GTB4 (Daytona) — Transmission Shaft (diagram 016)
Exploded view of the transmission shaft on the Ferrari 365 GTB4 (Daytona), with 29 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/016.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 640483 | Ferrari Transmission Tube - 640483 | Price on request | Contact us for price and availability |
| 2 | 560301 | Ferrari Drive Line Coupling - 560301 | $1,149.27 | Available, ships in 3-6 days |
| 2 | 560357 | Ferrari 365GTB/S4 Drive Line Joint - 560357 | Superseded | Order 560301 instead |
| 3 | 560265 | Ferrari Ring Clip - 560265 | $2.93 | Available, ships in 3-6 days |
| 4 | 560478 | Ferrari 365Gtb4 Prop Shaft Bush - 560478 | Price on request | Contact us for price and availability |
| 5 | 11060576 | Ferrari Snap Ring - 11060576 | $2.70 | Available, ships in 3-6 days |
| 6 | 95891401 | Ferrari Double Sealed Ball Race Self Aligning - 95891401 | $135.40 | Available, ships in 3-6 days |
| 7 | 11067376 | Ferrari Ring - 11067376 | $2.57 | Available, ships in 3-6 days |
| 8 | 560302 | Ferrari Mounting - 560302 | Price on request | Contact us for price and availability |
| 9 | 95181 | Ferrari Bolt - 95181 | $5.85 | Available, ships in 3-6 days |
| 10 | 127496 | Ferrari Spring Washer 8mm - 127496 | $0.12 | Available, ships in 3-6 days |
| 10 | 106852 | Ferrari Spring Washer 8mm - 106852 | Price on request | Special order, ships in 7-14 days |
| 11 | 560482 | Ferrari 365Gtb4 Prop Shaft - 560482 | Price on request | Contact us for price and availability |
| 12 | 102294 | Ferrari Bolt - 102294 | $4.71 | Available, ships in 3-6 days |
| 13 | 10516670 | Ferrari Spring Washer 8mm - 10516670 | Superseded | Order 127496 instead |
| 14 | 103181 | Ferrari Nut 8x1 - 103181 | $3.79 | Available, ships in 3-6 days |
| 15 | 15541124 | Ferrari Screw M12 x 1.25 x 65 - 15541124 | $1.67 | Available, ships in 3-6 days |
| 15 | 15541121 | Ferrari Bolt - 15541121 | $1.67 | Available, ships in 3-6 days |
| 16 | 10520020 | Ferrari Washer - 10520020 | Price on request | Contact us for price and availability |
| 17 | 16109221 | Ferrari Self Locking Nut M12 x 1.25 - 16109221 | $9.28 | Available, ships in 3-6 days |
| 17 | 95900614 | Ferrari Nut N70 112Ma - 95900614 | Price on request | Contact us for price and availability |
| 18 | 560469 | Ferrari Tension Bar - 560469 | Price on request | Contact us for price and availability |
| 19 | 95900704 | Ferrari Nut - 95900704 | $24.94 | Available, ships in 3-6 days |
| 20 | 104456 | Ferrari Washer - 104456 | $4.23 | Available, ships in 3-6 days |
| 20 | 94781 | Ferrari Washer - 94781 | $27.70 | Available, ships in 3-6 days |
| 21 | 520938 | Ferrari Cup - 520938 | Price on request | Contact us for price and availability |
| 22 | 100734 | Ferrari Bush - 100734 | $77.76 | Available, ships in 3-6 days |
| 22 | 520641 | Ferrari Rubber - 520641 | Superseded | Order 100734 instead |
| 100735 | Ferrari Cup - 100735 | Price on request | Contact us for price and availability |
