Ferrari 488 Pista — [VEHICLE TRIM] - E.40 - FRONT BUMPER (diagram 0141)

Exploded view of the [vehicle trim] - e.40 - front bumper on the Ferrari 488 Pista, with 72 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 488 Pista [VEHICLE TRIM] - E.40 - FRONT BUMPER exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
12574115Ferrari Nut - 12574115SupersededOrder 169180 instead
12577811Ferrari Nut - 12577811SupersededOrder 169180 instead
12574111Ferrari Nyloc Nut - 12574111SupersededOrder 169180 instead
12574121Ferrari Nyloc Nut White - 12574121SupersededOrder 169180 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
12646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
126648Ferrari Washer - 126648SupersededOrder 14496624 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
189270710Ferrari Compl. Front Bumper - 89270710$38,014.64Contact us to order
189375110Ferrari Compl. Front Bumper - 89375110$41,390.41Contact us to order
1985792848Ferrari Compl. Front Bumper - 985792848$43,919.53Contact us to order
1985792994Ferrari Compl. Front Bumper - 985792994$47,297.47Contact us to order
2824194Ferrari Compl. Upper Centre Spoiler - 824194$6,133.41Special order, ships in 7-14 days
2824297Ferrari Compl. Upper Centre Spoiler - 824297$6,009.85Special order, ships in 7-14 days
2875753Ferrari Compl. Upper Centre Spoiler - 875753SupersededOrder 70006188 instead
270006188Ferrari Complete Upper Centre Spoiler - 70006188$17,954.99Contact us to order
370006239Ferrari Compl. RH Lateral Spoiler - 70006239$12,534.91Contact us to order
3824123Ferrari Compl. RH Lateral Spoiler - 824123$5,828.02Special order, ships in 7-14 days
3824298Ferrari Compl. RH Lateral Spoiler - 824298$5,322.15Special order, ships in 7-14 days
3875869Ferrari Compl. RH Lateral Spoiler - 875869$6,594.98Special order, ships in 7-14 days
470006240Ferrari Compl. LH Lateral Spoiler - 70006240$12,534.91Contact us to order
4824025Ferrari Compl. LH Lateral Spoiler - 824025$5,828.02Special order, ships in 7-14 days
4824301Ferrari Compl. LH Lateral Spoiler - 824301$5,322.15Special order, ships in 7-14 days
4875873Ferrari Compl. LH Lateral Spoiler - 875873$6,594.98Special order, ships in 7-14 days
570006241Ferrari Compl. RH Lateral Under-Chin - 70006241$5,636.84Special order, ships in 7-14 days
5875876Ferrari Compl. RH Lateral Under-Chin - 875876SupersededOrder 70006241 instead
5807968Ferrari Compl. RH Lateral Under-Chin Element - 807968$4,510.87Special order, ships in 7-14 days
5891056Ferrari Compl. RH Lateral Under-Chin Element - 891056$783.26Special order, ships in 7-14 days
589363600Ferrari Compl. RH Lateral Under-Chin Element - 89363600SupersededOrder 891056 instead
670006242Ferrari Compl. LH Lateral Under-Chin - 70006242$5,636.84Special order, ships in 7-14 days
6875872Ferrari Compl. LH Lateral Under-Chin - 875872SupersededOrder 70006242 instead
6807967Ferrari Compl. LH Lateral Under-Chin Element - 807967$4,510.87Special order, ships in 7-14 days
6891065Ferrari Compl. LH Lateral Under-Chin Element - 891065$783.26Special order, ships in 7-14 days
689363700Ferrari Compl. LH Lateral Under-Chin Element - 89363700SupersededOrder 891065 instead
7343190Ferrari Front Parking Sensor Cable - 343190$514.01Special order, ships in 7-14 days
8242384Ferrari Clip - 242384$0.59Available, ships in 3-6 days
9807428Ferrari Completion Element For Front - 807428$758.79Special order, ships in 7-14 days
1065752800Ferrari Screw M4 x 10 TBEI - 65752800$4.12Available, ships in 3-6 days
1185833800Ferrari Screw M5 x 14 TBFTX - 85833800$0.90Available, ships in 3-6 days
1285941100Ferrari Head Lamp Washer - 85941100$12.59Available, ships in 3-6 days
13815413Ferrari Compl. RH Front Aluminium Mesh - 815413$1,022.60Special order, ships in 7-14 days
14815381Ferrari Compl. LH Front Aluminium Me - 815381$826.77Special order, ships in 7-14 days
1589272110Ferrari Lower Centre Spoiler - 89272110$6,233.64Special order, ships in 7-14 days
1689382400Ferrari Headlight Washer Pipe Assemb - 89382400$1,150.42Special order, ships in 7-14 days
1789382600Ferrari LH Headlamp Washer Mount Bracket - 89382600$7.55Special order, ships in 7-14 days
1789382500Ferrari RH Headlamp Washer Mount Bracket - 89382500$7.55Special order, ships in 7-14 days
1887327900Ferrari Single Mounting Spacer - 87327900$3.68Special order, ships in 7-14 days
19973053Ferrari Front Emblem/Badge - 973053$368.80In stock
1965394800Ferrari Nose Emblem Badge - 65394800SupersededOrder 973053 instead
20295361Ferrari Parking Sensor - 295361$80.91In stock
21770065Ferrari Front Parking Camera - 770065$2,471.06Special order, ships in 7-14 days
2214417921Ferrari Screw M3 x 6 - 14417921$4.54Available, ships in 3-6 days
2381544800Ferrari/Maserati Parking Sensor Ring - 81544800$11.59In stock
2486886800Ferrari Camera Fastener Bracket - 86886800$342.66Special order, ships in 7-14 days
2585691900Ferrari Screw M5 x 8 TBFTX - 85691900$0.65Available, ships in 3-6 days
26169180Ferrari Nyloc Nut M5 x 6.3 - 169180$0.31Available, ships in 3-6 days
2714433124Ferrari Screw 6x18 - 14433124$0.34Available, ships in 3-6 days
2812647604Ferrari Washer - 12647604$0.12Available, ships in 3-6 days
2981591700Ferrari Screw TE M6 x 18 with washer - 81591700$4.12Available, ships in 3-6 days
3014496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
31878454Ferrari RH Front Bumper Impact Absor - 878454$124.81Special order, ships in 7-14 days
32878455Ferrari LH Front Bumper Impact Absor - 878455$124.81Special order, ships in 7-14 days
3314305974Ferrari Allen Screw - 14305974$0.55In stock
3414498801Ferrari Washer - 14498801$0.19Available, ships in 3-6 days
35790708Ferrari RH Crash Bracket - 790708$51.37Special order, ships in 7-14 days
36790709Ferrari LH Crash Bracket - 790709$51.37Special order, ships in 7-14 days
3887329500Ferrari LH Front Side Marker - 87329500$122.36Available, ships in 3-6 days
3887329600Ferrari RH Front Side Marker - 87329600$122.36Special order, ships in 7-14 days
3989241300Ferrari Nut - 89241300$32.76Special order, ships in 7-14 days

All 488 Pista diagrams
