Ferrari 812 Competizione — [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS (diagram 0157)

Exploded view of the [vehicle trim] - e.47.09 - dashboard - fasteners on the Ferrari 812 Competizione, with 72 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 812 Competizione [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14048115Ferrari Nut - 14048115SupersededOrder 14058411 instead
14048611Ferrari Nut - 14048611SupersededOrder 14058411 instead
14048615Ferrari Nut - 14048615SupersededOrder 14058411 instead
192623Ferrari Screw - 192623$5.40Special order, ships in 7-14 days
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
290589Ferrari Screw 4x8 - 290589SupersededOrder 309629 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
14368371Ferrari Screw Clip - 14368371SupersededOrder 14188971 instead
106853Ferrari Spring Washer 10mm - 106853SupersededOrder 12601474 instead
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
10516873Ferrari Washer - 10516873SupersededOrder 12601474 instead
12600479Ferrari Washer - 12600479$0.38Available, ships in 3-6 days
12601471Ferrari Washer - 12601471SupersededOrder 12601474 instead
12638108Ferrari Washer - 12638108SupersededOrder 12638178 instead
12638177Ferrari Washer - 12638177SupersededOrder 12638178 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
61276300Ferrari Washer - 61276300SupersededOrder 12638178 instead
14496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
124338Ferrari Washer D. 8 - 25 x 3 - 124338$14.55Available, ships in 3-6 days
1914583Ferrari Rubber Shim - 914583$5.65Special order, ships in 7-14 days
210794011Ferrari Nut M4 x 0.7mm - 10794011$0.06Available, ships in 3-6 days
385692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
484939300Ferrari Screw - 84939300$37.13Special order, ships in 7-14 days
512638178Ferrari Washer 5.45-14x1 - 12638178$0.13Available, ships in 3-6 days
685834000Ferrari Screw M5 x 25 - 85834000$0.71Special order, ships in 7-14 days
685834100Ferrari Screw M5 x 30 TBFTX - 85834100$0.79Special order, ships in 7-14 days
714188971Ferrari Screw Clip - 14188971$9.07Special order, ships in 7-14 days
865752800Ferrari Screw M4 x 10 TBEI - 65752800$4.12Available, ships in 3-6 days
913025787Ferrari Screw - 13025787$0.84Special order, ships in 7-14 days
985692000Ferrari SCREW - 85692000$0.65Available, ships in 3-6 days
1015782504Ferrari Screw 3.5x10 - 15782504$0.86Available, ships in 3-6 days
1182535800Ferrari Press Fastener Pin - 82535800$3.03Available, ships in 3-6 days
1214418074Ferrari Screw M3x8 - 14418074$0.40Available, ships in 3-6 days
1385691900Ferrari Screw M5 x 8 TBFTX - 85691900$0.65Available, ships in 3-6 days
1412647624Ferrari Washer D 6.45-16x2 - 12647624$0.19Available, ships in 3-6 days
15231625Ferrari Screw 6x50 - 231625$1.25Available, ships in 3-6 days
1784761600Ferrari Clip - 84761600$0.79Special order, ships in 7-14 days
1816284934Ferrari Screw - 16284934$1.61Available, ships in 3-6 days
1816284927Ferrari Screw 5x10 - 16284927SupersededOrder 16284934 instead
1916286024Ferrari SCREW - 16286024$0.38Available, ships in 3-6 days
1916285124Ferrari Screw 5x16 - 16285124SupersededOrder 16286024 instead
2015538777Ferrari Screw 8x13 - 15538777$0.34Available, ships in 3-6 days
2113270417Ferrari Screw 3x8 - 13270417$0.13Special order, ships in 7-14 days
2263343400Ferrari Screw 4x15 - 63343400$5.02Available, ships in 3-6 days
2314058411Ferrari Flanged Nut M6 x 6mm - 14058411$0.38Available, ships in 3-6 days
2468700200Ferrari Fixing Clip - 68700200$10.68Special order, ships in 7-14 days
25219344Ferrari Washer D8.5x24x - 219344SupersededOrder 124338 instead
2616043634Ferrari Screw M8 x 25 - 16043634$0.40Available, ships in 3-6 days
2767278400Ferrari BRACKET - 67278400$21.60Special order, ships in 7-14 days
2885833900Ferrari Screw M5 x 16 TBFTX - 85833900$0.65Available, ships in 3-6 days
2914039511Ferrari Nut - 14039511$0.54Available, ships in 3-6 days
3015687204Ferrari Screw 3.5x13 - 15687204$0.90Available, ships in 3-6 days
3118752121Ferrari Screw 8x18 - 18752121$1.17Special order, ships in 7-14 days
3312600474Ferrari Washer - 12600474$0.06Available, ships in 3-6 days
3412678877Ferrari Screw - 12678877$6.96Special order, ships in 7-14 days
3585692300Ferrari Screw M5 x 20 TBFTX - 85692300$0.65Available, ships in 3-6 days
3612647024Ferrari Washer - 12647024$1.02Available, ships in 3-6 days
3716287624Ferrari Screw 8x45 - 16287624$5.02Available, ships in 3-6 days
3814447078Ferrari Washer D. 5.5 - 15 x 1 - 14447078$0.54Special order, ships in 7-14 days
3985833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
3911566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
4014059121Ferrari Nut M5 - 14059121$0.31Available, ships in 3-6 days
4181912400Ferrari Screw 3.5x10 - 81912400$0.12Available, ships in 3-6 days
42309629Ferrari Screw 4x8 - 309629$4.77Special order, ships in 7-14 days
4388424000Ferrari Stud Bolt - 88424000$17.67Special order, ships in 7-14 days
4388562900Ferrari Stud Bolt - 88562900$15.05Special order, ships in 7-14 days
4412646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
4512601474Ferrari Wavy Washer 10mm - 12601474$0.06Available, ships in 3-6 days
4614308574Ferrari Allen Screw 10x1.25x90 - 14308574$7.40Available, ships in 3-6 days
4714302924Ferrari Screw - 14302924$0.44Available, ships in 3-6 days
4810523424Ferrari Washer D 6.15-18x2 - 10523424$0.92Available, ships in 3-6 days

All 812 Competizione diagrams
