Ferrari 812 CompetizioneA — [MECHANICAL SYSTEM] - D.27.02 - REAR SUSPENSION - ARMS (diagram 0080)

Exploded view of the [mechanical system] - d.27.02 - rear suspension - arms on the Ferrari 812 CompetizioneA, with 67 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 812 CompetizioneA [MECHANICAL SYSTEM] - D.27.02 - REAR SUSPENSION - ARMS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
238693Ferrari Camber Spacer 1.0mm - 238693$10.25Special order, ships in 7-14 days
238881Ferrari Camber Spacer 1.5mm - 238881$10.25Special order, ships in 7-14 days
238882Ferrari Camber Spacer 2.5mm - 238882$10.25Special order, ships in 7-14 days
238884Ferrari Camber Spacer 3.5mm - 238884$10.25Special order, ships in 7-14 days
238885Ferrari Camber Spacer 4.0mm - 238885$10.25Special order, ships in 7-14 days
314774Ferrari LH Rear Lower Arm Complete - 314774SupersededOrder 911176 instead
329243Ferrari LH Rear Lower Arm Complete - 329243SupersededOrder 911176 instead
16104125Ferrari Nut - 16104125SupersededOrder 104030 instead
12575621Ferrari Nyloc Nut - 12575621SupersededOrder 102742 instead
340271Ferrari Potentiometer Tie-Rod - 340271SupersededOrder 984044 instead
236783Ferrari Rear Suspension Link Arm - 236783SupersededOrder 259688 instead
314775Ferrari RH Rear Lower Arm Complete - 314775SupersededOrder 911175 instead
329244Ferrari RH Rear Lower Arm Complete - 329244SupersededOrder 911175 instead
190870Ferrari Screw 6x14 - 190870$4.10Special order, ships in 7-14 days
765410Ferrari Sensore Di Spostam. Post Cpl - 765410$328.27Special order, ships in 7-14 days
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
12646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
126648Ferrari Washer - 126648SupersededOrder 14496624 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
1843923Ferrari Compl. LH Rear Hub Carrier - 843923$3,868.51Special order, ships in 7-14 days
1843963Ferrari Compl. RH Rear Hub Carrier - 843963$3,868.51Special order, ships in 7-14 days
2203666Ferrari Nut - 203666$1.80Available, ships in 3-6 days
314496721Ferrari Washer - 14496721$0.19Special order, ships in 7-14 days
4763942Ferrari Compl. LH Actuator - 763942$10,397.24Special order, ships in 7-14 days
4763943Ferrari Compl. RH Actuator - 763943$10,397.24Special order, ships in 7-14 days
515541434Ferrari Screw 12x1.25x80 - 15541434$4.12Special order, ships in 7-14 days
6336026Ferrari ABS Sensor - 336026$120.18Available, ships in 3-6 days
8310942Ferrari Triple Clip - 310942$3.26Special order, ships in 7-14 days
9250657Ferrari Screw M6 x 14 TBTX - 250657$13.36Available, ships in 3-6 days
10238656Ferrari Special Screw TCEI M14 x 1.5 x 21 - 238656$45.87Available, ships in 3-6 days
11896443Ferrari Compl. LH Rear Lower Arm - 896443SupersededOrder 911176 instead
11911176Ferrari Compl. LH Rear Lower Arm - 911176$1,745.74Special order, ships in 7-14 days
11896445Ferrari Compl. RH Rear Lower Arm - 896445SupersededOrder 911175 instead
11911175Ferrari Compl. RH Rear Lower Arm - 911175$1,745.74Special order, ships in 7-14 days
1216284934Ferrari Screw - 16284934$1.61Available, ships in 3-6 days
1216284927Ferrari Screw 5x10 - 16284927SupersededOrder 16284934 instead
13238063Ferrari Nut M14 x 1.x - 238063$7.40Available, ships in 3-6 days
14259688Ferrari Anti Rotation Linkage - 259688$295.03Special order, ships in 7-14 days
15222956Ferrari Compensator Ring 24x12 - 222956$20.76Available, ships in 3-6 days
16238258Ferrari Screw M12 x 1.25 x 75 - 238258$63.37Special order, ships in 7-14 days
17104114Ferrari Nyloc Nut M10 x 1.25 x 12 - 104114$0.73Available, ships in 3-6 days
1814496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
19263032Ferrari Camber Spacer 0.5mm - 263032$24.02Available, ships in 3-6 days
19263033Ferrari Camber Spacer 1.0mm - 263033$7.19Special order, ships in 7-14 days
19263034Ferrari Camber Spacer 1.5mm - 263034$7.19Special order, ships in 7-14 days
19238694Ferrari Camber Spacer 2.0mm - 238694SupersededOrder 263035 instead
19263035Ferrari Camber Spacer 2.0mm - 263035$7.19Available, ships in 3-6 days
19263036Ferrari Camber Spacer 2.5mm - 263036$10.25Special order, ships in 7-14 days
19263037Ferrari Camber Spacer 3.0mm - 263037SupersededOrder 238883 instead
19263038Ferrari Camber Spacer 3.5mm - 263038$10.25Special order, ships in 7-14 days
19263039Ferrari Camber Spacer 4.0mm - 263039$10.25Special order, ships in 7-14 days
20264528Ferrari Threaded Rod 10x1.25 - 264528$7.63Available, ships in 3-6 days
21343376Ferrari Ball Joint - 343376$34.40Special order, ships in 7-14 days
22984051Ferrari Sensore Di Spostam. Post Cpl - 984051$305.96Special order, ships in 7-14 days
23984044Ferrari Potentiometer Tie-Rod - 984044$270.44Special order, ships in 7-14 days
24340273Ferrari Ball Joint - 340273$88.49Special order, ships in 7-14 days
2514040614Ferrari Flanged Nut 6mm - 14040614$0.27Available, ships in 3-6 days
26314125Ferrari Actuator Cable Fastener Brac - 314125$39.31Special order, ships in 7-14 days
27269959Ferrari Screw - 269959$1.61In stock
28295792Ferrari Rear Upper Arm - 295792$888.98Available, ships in 3-6 days
29104030Ferrari/Maserati Nut - 104030$0.88In stock
3014496524Ferrari Washer - 14496524$0.19Available, ships in 3-6 days
3113578321Ferrari Washer D.8.15-24x2 - 13578321$1.04Available, ships in 3-6 days
32302406Ferrari Threaded Rod - 302406$4.77Special order, ships in 7-14 days
33829997Ferrari LH Rear Bracket - 829997$140.13Special order, ships in 7-14 days
33830032Ferrari RH Rear Bracket - 830032$140.13Special order, ships in 7-14 days

All 812 CompetizioneA diagrams
