Ferrari 812 GTS — REAR BUMPER (diagram 0119)

Exploded view of the rear bumper on the Ferrari 812 GTS, with 104 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 812 GTS REAR BUMPER exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
85309700Ferrari Centre Heat Shield - 85309700$215.38Special order, ships in 7-14 days
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
11566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
14498804Ferrari Washer - 14498804SupersededOrder 14498824 instead
1985890810Ferrari Compl. Rear Bumper - 985890810$20,884.00Contact us to order
1985916531Ferrari Compl. Rear Bumper - 985916531$25,620.11Contact us to order
1985940572Ferrari Compl. Rear Bumper - 985940572$17,106.82Contact us to order
1985940579Ferrari Compl. Rear Bumper - 985940579$19,953.26Contact us to order
1985890787Ferrari Complete Rear Bumper - 985890787$17,041.73Contact us to order
1985901161Ferrari Complete Rear Bumper - 985901161$19,875.16Contact us to order
2896428Ferrari Complete Centre Mount for Rear Bumper - 896428$71.28Special order, ships in 7-14 days
3985909324Ferrari Mostrina Fanale Dx Cpl Semil - 985909324$786.79Special order, ships in 7-14 days
4985909300Ferrari Mostrina Fanale Sx Cpl Semil - 985909300$786.79Special order, ships in 7-14 days
589011800Ferrari Snap-On Clip - 89011800$29.48Special order, ships in 7-14 days
685692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
712644401Ferrari Washer - 12644401$0.08Available, ships in 3-6 days
889336000Ferrari Shim Plate - 89336000$9.16Special order, ships in 7-14 days
9256490Ferrari Screw TBEI M5 x 16 - 256490$3.91Available, ships in 3-6 days
10500649/KFerrari Clutch Tension Adjuster Kit - 500649/K$123.64Available, ships in 3-6 days
1012646701Ferrari Washer D. 8.45 - 20 x 2 - 12646701$0.17Available, ships in 3-6 days
1189037800Ferrari RH Reflector - 89037800$152.97Special order, ships in 7-14 days
1289037700Ferrari LH Reflector - 89037700$152.97Special order, ships in 7-14 days
1389013200Ferrari RH Reflector Heat Shield - 89013200$467.15Special order, ships in 7-14 days
1489013100Ferrari LH Reflector Heat Shield - 89013100$467.15Special order, ships in 7-14 days
1588106300Ferrari RH Lateral Rear Bumper Mount - 88106300$27.03Special order, ships in 7-14 days
1688130600Ferrari LH Rear Lateral Bumper Mount - 88130600$27.03Special order, ships in 7-14 days
1714039511Ferrari Nut - 14039511$0.54Available, ships in 3-6 days
1881290900Ferrari Screw With Double Washer - 81290900$1.42In stock
19295361Ferrari Parking Sensor - 295361$80.91In stock
2088135100Ferrari Centre Heat Shield - 88135100$174.55Special order, ships in 7-14 days
2181544800Ferrari/Maserati Parking Sensor Ring - 81544800$11.59In stock
2284784600Ferrari Washer For Pin - 84784600$43.68Special order, ships in 7-14 days
23764639Ferrari RH Tailpipes With Mesh - 764639$4,887.43Special order, ships in 7-14 days
23764642Ferrari RH Tailpipes With Mesh - 764642$2,350.03Special order, ships in 7-14 days
2388768600Ferrari RH Tailpipes With Mesh - 88768600$808.64Special order, ships in 7-14 days
2388873700Ferrari RH Tailpipes With Mesh - 88873700$786.79Special order, ships in 7-14 days
2389381100Ferrari RH Tailpipes With Mesh - 89381100$4,887.43Special order, ships in 7-14 days
2389381600Ferrari RH Tailpipes With Mesh - 89381600$2,254.27Special order, ships in 7-14 days
24764638Ferrari LH Tailpipes With Mesh - 764638$4,887.43Special order, ships in 7-14 days
24764640Ferrari LH Tailpipes With Mesh - 764640$2,350.03Special order, ships in 7-14 days
2488768500Ferrari LH Tailpipes With Mesh - 88768500$808.64Special order, ships in 7-14 days
2488873600Ferrari LH Tailpipes With Mesh - 88873600$786.79Special order, ships in 7-14 days
2489381000Ferrari LH Tailpipes With Mesh - 89381000$4,887.43Special order, ships in 7-14 days
2489381500Ferrari LH Tailpipes With Mesh - 89381500$2,254.27Special order, ships in 7-14 days
2588710300Ferrari Screw - 88710300$1.09Special order, ships in 7-14 days
2687547900Ferrari Washer - 87547900$1.99Special order, ships in 7-14 days
2784583500Ferrari Fastener clip - 84583500$2.59Available, ships in 3-6 days
2870006289Ferrari Guancia Laterale Dx Carb. Ex - 70006289$8,589.44Special order, ships in 7-14 days
2888768400Ferrari RH Side Fairing - 88768400$2,271.45Special order, ships in 7-14 days
2889230800Ferrari RH Side Fairing - 89230800$5,121.33Special order, ships in 7-14 days
2970006290Ferrari Guancia Laterale Sx Carb. Ex - 70006290$8,589.44Special order, ships in 7-14 days
2988768300Ferrari LH Side Fairing - 88768300$2,271.45Special order, ships in 7-14 days
2989230700Ferrari LH Side Fairing - 89230700$5,098.33Special order, ships in 7-14 days
30760157Ferrari RH Lower Mesh - 760157$546.38Special order, ships in 7-14 days
31760156Ferrari LH Lower Mesh - 760156$546.38Special order, ships in 7-14 days
32760153Ferrari Part Search Results - 760153$467.15Special order, ships in 7-14 days
33760146Ferrari LH Heat Shield - 760146$467.15Special order, ships in 7-14 days
3489013000Ferrari RH Lateral Heat Shield - 89013000$491.74Special order, ships in 7-14 days
3589012900Ferrari LH Lateral Heat Shield - 89012900$491.74Special order, ships in 7-14 days
36760142Ferrari Part Search Results - 760142$344.21Special order, ships in 7-14 days
37760141Ferrari LH Rear Air Intake - 760141$342.66Special order, ships in 7-14 days
3880874300Ferrari Clip - 80874300$1.97Available, ships in 3-6 days
3914642294Ferrari Rivet - 14642294$1.36Available, ships in 3-6 days
40324182Ferrari Bighead - 324182$16.45Special order, ships in 7-14 days
4187546400Ferrari Round Fastener - 87546400$10.91Special order, ships in 7-14 days
4282115900Ferrari Screw M6 x 14 With Washer - 82115900$1.23Available, ships in 3-6 days
4384053900Ferrari Rivet - 84053900$44.24Available, ships in 3-6 days
44891426Ferrari Centre Mounting Bracket for Rear Bumper - 891426$103.25Special order, ships in 7-14 days
4585687400Ferrari 488 Rear Bumper Screw - 85687400$4.16In stock
4687548900Ferrari RH Mounting Bracket for Rear Bumper - 87548900$174.55Special order, ships in 7-14 days
4714059214Ferrari Flanged Nut M6 - 14059214$0.38Available, ships in 3-6 days
4812640624Ferrari Plain Washer 6mm - 12640624$0.31Available, ships in 3-6 days
49891423Ferrari LH Mounting Bracket for Rear Bumper - 891423$100.78Special order, ships in 7-14 days
5010902387Ferrari Screw M6 x 18 - 10902387$1.61Available, ships in 3-6 days
5081045300Ferrari Screw 6x16 - 81045300$1.36Special order, ships in 7-14 days
5112647778Ferrari Cup Washer - 12647778$0.82Available, ships in 3-6 days
5370007163Ferrari Rear Bumper Diffuser - 70007163$32,356.54Contact us to order
53873107Ferrari Rear Bumper Diffuser - 873107$15,598.23Contact us to order
53896235Ferrari Rear Bumper Diffuser - 896235$10,240.35Contact us to order
53911818Ferrari Rear Bumper Diffuser - 911818$11,296.47Contact us to order
5412578211Ferrari Flanged Nyloc Nut - 12578211$0.57Special order, ships in 7-14 days
55892909Ferrari Rete_Centrale_Paraurto_Post - 892909$1,245.78Special order, ships in 7-14 days
5686794700Ferrari Clip - 86794700$2.59Available, ships in 3-6 days
5788933300Ferrari Compl. Aerodynamic Extractor - 88933300$2,603.98Contact us to order
5813046014Ferrari Nut - 13046014$0.63Special order, ships in 7-14 days
5983442900Ferrari Body Screw - 83442900$1.51In stock
60890820Ferrari RH Aero Extractor Cover - 890820$174.55Special order, ships in 7-14 days
61890819Ferrari LH Aero Extractor Cover - 890819$174.55Special order, ships in 7-14 days
6288766400Ferrari Central Hatch - 88766400$614.67Special order, ships in 7-14 days
6388766500Ferrari RH Side Hatches - 88766500$565.49Special order, ships in 7-14 days
6488766600Ferrari LH Side Hatches - 88766600$565.49Special order, ships in 7-14 days
6585692300Ferrari Screw M5 x 20 TBFTX - 85692300$0.65Available, ships in 3-6 days
66807298Ferrari Screw - 807298$30.57Special order, ships in 7-14 days
67774877Ferrari Washer - 774877$1.82Special order, ships in 7-14 days
67791018Ferrari Washer - 791018$0.92Special order, ships in 7-14 days
6812647724Ferrari Washer - 12647724$0.31Available, ships in 3-6 days
6914039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
6915896214Ferrari Nut M6 x 5 - 15896214SupersededOrder 14039614 instead
7065212000Ferrari Screw 5x8 - 65212000SupersededOrder 85691900 instead
7185833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
72881896Ferrari Rear Bumper Impact Absorber - 881896$344.21Special order, ships in 7-14 days
73881895Ferrari Bumper Reinforcement Cross-M - 881895$1,106.43Special order, ships in 7-14 days
75782291Ferrari Rear License Plate Holder - 782291$393.38Special order, ships in 7-14 days

All 812 GTS diagrams
