Ferrari 812 Superfast — Electric Steering Box (diagram 029)
Exploded view of the electric steering box on the Ferrari 812 Superfast, with 21 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 327735 | Ferrari Compl. Electric Steering Box - 327735 | $18,864.14 | Special order, ships in 7-14 days |
| 1 | 318803 | Ferrari Compl. Electric Steering Box - 318803 | $25,159.50 | Special order, ships in 7-14 days |
| 2 | 337238 | Ferrari Compl. Eps Motor Heat Shield - 337238 | $491.74 | Special order, ships in 7-14 days |
| 2 | 334234 | Ferrari Compl. Eps Motor Heat Shield - 334234 | $663.86 | Special order, ships in 7-14 days |
| 3 | 333073 | Ferrari Eps Cooling Duct - 333073 | $147.51 | Special order, ships in 7-14 days |
| 3 | 333811 | Ferrari Eps Cooling Duct - 333811 | $213.88 | Special order, ships in 7-14 days |
| 4 | 316032 | Ferrari Washer - 316032 | $3.03 | Available, ships in 3-6 days |
| 5 | 149807 | Ferrari Self-Locking Nut For Top And Bottom Ball Joints - 149807 | $2.13 | Available, ships in 3-6 days |
| 6 | 277720 | Ferrari Screw M10 x 1.25 x 80 - 277720 | $7.84 | Available, ships in 3-6 days |
| 7 | 14496624 | Ferrari Washer D. 10.50-21 x2 - 14496624 | $0.12 | Available, ships in 3-6 days |
| 8 | 14058621 | Ferrari Flanged Nut M10 x 1.25 x 11.8 - 14058621 | $0.79 | Special order, ships in 7-14 days |
| 9 | 233600 | Ferrari/Maserati Screw - 233600 | $1.98 | In stock |
| 10 | 296781 | Ferrari Hose Clamp - 296781 | $5.59 | In stock |
| 11 | 278577 | Ferrari Tube Clamp D.30-40mm - 278577 | $3.68 | Special order, ships in 7-14 days |
| 12 | 269315 | Ferrari Clip - 269315 | $1.94 | Special order, ships in 7-14 days |
| 839412 | Ferrari Compl. Electric Steering Box - 839412 | $19,844.79 | Special order, ships in 7-14 days | |
| 14496609 | Ferrari Steel Washer - 14496609 | Superseded | Order 12646824 instead | |
| 12646824 | Ferrari Washer - 12646824 | Superseded | Order 14496624 instead | |
| 126648 | Ferrari Washer - 126648 | Superseded | Order 14496624 instead | |
| 14496601 | Ferrari Washer - 14496601 | Superseded | Order 12646824 instead | |
| 14496621 | Ferrari Washer - 14496621 | Superseded | Order 12646824 instead |
