Ferrari Daytona SP3 — [MECHANICAL SYSTEM] - D.25.02 - FRONT SUSPENSION - ARMS (diagram 0076)

Exploded view of the [mechanical system] - d.25.02 - front suspension - arms on the Ferrari Daytona SP3, with 74 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Daytona SP3 [MECHANICAL SYSTEM] - D.25.02 - FRONT SUSPENSION - ARMS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
238693Ferrari Camber Spacer 1.0mm - 238693$10.25Special order, ships in 7-14 days
238881Ferrari Camber Spacer 1.5mm - 238881$10.25Special order, ships in 7-14 days
238694Ferrari Camber Spacer 2.0mm - 238694SupersededOrder 263035 instead
238882Ferrari Camber Spacer 2.5mm - 238882$10.25Special order, ships in 7-14 days
238884Ferrari Camber Spacer 3.5mm - 238884$10.25Special order, ships in 7-14 days
238885Ferrari Camber Spacer 4.0mm - 238885$10.25Special order, ships in 7-14 days
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
16104125Ferrari Nut - 16104125SupersededOrder 104030 instead
12575621Ferrari Nyloc Nut - 12575621SupersededOrder 102742 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
190870Ferrari Screw 6x14 - 190870$4.10Special order, ships in 7-14 days
764759Ferrari Sensore Di Spostam. Posterio - 764759$326.35Special order, ships in 7-14 days
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
13543721Ferrari Stud - 13543721SupersededOrder 13543724 instead
12646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
126648Ferrari Washer - 126648SupersededOrder 14496624 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
1744452Ferrari Compl. LH Front Hub Carrier - 744452$9,064.81Special order, ships in 7-14 days
1744456Ferrari Compl. RH Front Hub Carrier - 744456$9,064.81Special order, ships in 7-14 days
2305467Ferrari LH Lower Front Anrm Complete - 305467SupersededOrder 308585 instead
2308585Ferrari LH Lower Front Anrm Complete - 308585$2,578.21Special order, ships in 7-14 days
2315459Ferrari LH Lower Front Anrm Complete - 315459Price on requestContact us for price and availability
2305468Ferrari RH Lower Front Anrm Complete - 305468SupersededOrder 308586 instead
2308586Ferrari RH Lower Front Anrm Complete - 308586$2,578.21Special order, ships in 7-14 days
2315461Ferrari RH Lower Front Anrm Complete - 315461SupersededOrder 308586 instead
3241689Ferrari Spacer - 241689$14.62Special order, ships in 7-14 days
4203795Ferrari Nut M14 x 1.5 - 203795$4.56Available, ships in 3-6 days
514040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
6250657Ferrari Screw M6 x 14 TBTX - 250657$13.36Available, ships in 3-6 days
7297986Ferrari LH Front Upper Arm Complete - 297986$3,018.46Special order, ships in 7-14 days
7297987Ferrari RH Front Upper Arm Complete - 297987$3,018.46Special order, ships in 7-14 days
812646921Ferrari Washer - 12646921$0.92Available, ships in 3-6 days
9149807Ferrari Self-Locking Nut For Top And Bottom Ball Joints - 149807$2.13Available, ships in 3-6 days
1013543724Ferrari Stud Bolt M8x16 -Shank length 35- - 13543724$3.26Special order, ships in 7-14 days
11104030Ferrari/Maserati Nut - 104030$0.88In stock
1214496524Ferrari Washer - 14496524$0.19Available, ships in 3-6 days
13305454Ferrari Adjustment Shim 0.5mm - 305454$10.68Special order, ships in 7-14 days
13305455Ferrari Adjustment Shim 1.0mm - 305455$10.68Special order, ships in 7-14 days
13305456Ferrari Adjustment Shim 1.5mm - 305456$10.68Special order, ships in 7-14 days
13305457Ferrari Adjustment Shim 2.0mm - 305457$10.68Special order, ships in 7-14 days
13305458Ferrari Adjustment Shim 2.5mm - 305458$10.68Special order, ships in 7-14 days
13305459Ferrari Adjustment Shim 3.0mm - 305459$10.68Special order, ships in 7-14 days
13305460Ferrari Adjustment Shim 3.5mm - 305460$10.68Special order, ships in 7-14 days
13305461Ferrari Adjustment Shim 4.0mm - 305461$10.68Special order, ships in 7-14 days
1413546634Ferrari Stud Bolt - 13546634$61.45Special order, ships in 7-14 days
15104114Ferrari Nyloc Nut M10 x 1.25 x 12 - 104114$0.73Available, ships in 3-6 days
1614496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
17263032Ferrari Camber Spacer 0.5mm - 263032$24.02Available, ships in 3-6 days
17263033Ferrari Camber Spacer 1.0mm - 263033$7.19Special order, ships in 7-14 days
17263034Ferrari Camber Spacer 1.5mm - 263034$7.19Special order, ships in 7-14 days
17263035Ferrari Camber Spacer 2.0mm - 263035$7.19Available, ships in 3-6 days
17263036Ferrari Camber Spacer 2.5mm - 263036$10.25Special order, ships in 7-14 days
17238883Ferrari Camber Spacer 3.0mm - 238883$10.25Available, ships in 3-6 days
17263037Ferrari Camber Spacer 3.0mm - 263037SupersededOrder 238883 instead
17263038Ferrari Camber Spacer 3.5mm - 263038$10.25Special order, ships in 7-14 days
17263039Ferrari Camber Spacer 4.0mm - 263039$10.25Special order, ships in 7-14 days
1813543734Ferrari Stud - 13543734$3.26Available, ships in 3-6 days
1913578321Ferrari Washer D.8.15-24x2 - 13578321$1.04Available, ships in 3-6 days
20984046Ferrari Sensore Di Spostam. Posterio - 984046$327.81Special order, ships in 7-14 days
21340273Ferrari Ball Joint - 340273$88.49Special order, ships in 7-14 days
22984047Ferrari Potentiometer Link L=80Mm - 984047$270.44Special order, ships in 7-14 days
23216973Ferrari Ball Joint D8 M6x1 - 216973$6.54Available, ships in 3-6 days
24871055Ferrari LH Front Travel Sensor Faste - 871055$56.52Special order, ships in 7-14 days
24871056Ferrari RH Front Travel Sensor Faste - 871056$56.52Special order, ships in 7-14 days
2516284934Ferrari Screw - 16284934$1.61Available, ships in 3-6 days
2516284927Ferrari Screw 5x10 - 16284927SupersededOrder 16284934 instead
26295999Ferrari LH Front Joint Bracket - 295999$164.72Special order, ships in 7-14 days
26296000Ferrari RH Front Joint Bracket - 296000$164.72Special order, ships in 7-14 days
27231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
2816286024Ferrari SCREW - 16286024$0.38Available, ships in 3-6 days
29336025Ferrari ABS Sensor - 336025$120.18Special order, ships in 7-14 days
31292420Ferrari LH Front Joint Bracket - 292420$216.35Special order, ships in 7-14 days
31292421Ferrari RH Front Joint Jacket - 292421$216.35Special order, ships in 7-14 days

All Daytona SP3 diagrams
