Ferrari F8 Tributo — [MECHANICAL SYSTEM] - D.31 - STEERING BOX (diagram 0086)
Exploded view of the [mechanical system] - d.31 - steering box on the Ferrari F8 Tributo, with 38 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [MECHANICAL SYSTEM] - D.31 - STEERING BOX exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0086.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 15888824 | Ferrari Bolt - 15888824 | Superseded | Order 15888821 instead | |
| 228142 | Ferrari Clamp 20.2-22.8x9.2 - 228142 | Superseded | Order 13126070 instead | |
| 103403 | Ferrari Gasket - 103403 | Superseded | Order 10280060 instead | |
| 12575611 | Ferrari Nut - 12575611 | Superseded | Order 102742 instead | |
| 12575621 | Ferrari Nyloc Nut - 12575621 | Superseded | Order 102742 instead | |
| 12575625 | Ferrari Nyloc Nut - 12575625 | Superseded | Order 102742 instead | |
| 262825 | Ferrari Pipe From Steering Box to Rad - 262825 | Superseded | Order 305041 instead | |
| 16237074 | Ferrari Screw - 16237074 | Superseded | Order 16237374 instead | |
| 16237174 | Ferrari Screw - 16237174 | Superseded | Order 16237374 instead | |
| 14496609 | Ferrari Steel Washer - 14496609 | Superseded | Order 12646824 instead | |
| 100501 | Ferrari Washer - 100501 | Superseded | Order 10280060 instead | |
| 100511 | Ferrari Washer - 100511 | Superseded | Order 10280060 instead | |
| 12646824 | Ferrari Washer - 12646824 | Superseded | Order 14496624 instead | |
| 126648 | Ferrari Washer - 126648 | Superseded | Order 14496624 instead | |
| 14496601 | Ferrari Washer - 14496601 | Superseded | Order 12646824 instead | |
| 14496621 | Ferrari Washer - 14496621 | Superseded | Order 12646824 instead | |
| 95108 | Ferrari Washer - 95108 | Superseded | Order 10280060 instead | |
| 1 | 291133 | Ferrari 458/488/F8 Steering Rack (refundable core charge included) - 291133 | $4,612.50 | In stock |
| 1 | 301996 | Ferrari Steering Box RHD - 301996 | $9,129.12 | Special order, ships in 7-14 days |
| 2 | 785840 | Ferrari Pipe From Steering Box To Ra - 785840 | $128.01 | Special order, ships in 7-14 days |
| 2 | 305041 | Ferrari Pipe From Steering Box to Rad LHD - 305041 | $243.74 | Special order, ships in 7-14 days |
| 3 | 266248 | Ferrari Clip - 266248 | $4.14 | Special order, ships in 7-14 days |
| 3 | 304443 | Ferrari Clip - 304443 | $1.36 | Special order, ships in 7-14 days |
| 4 | 277407 | Ferrari Union - 277407 | $17.46 | Special order, ships in 7-14 days |
| 5 | 15888821 | Ferrari Bolt - 15888821 | $8.53 | Available, ships in 3-6 days |
| 5 | 16237374 | Ferrari Screw 10x1.25x70 - 16237374 | Superseded | Order 15888821 instead |
| 6 | 13126070 | Ferrari Collar - 13126070 | $1.99 | Available, ships in 3-6 days |
| 6 | 13127070 | Ferrari Collar - 13127070 | Superseded | Order 13126070 instead |
| 7 | 14058621 | Ferrari Flanged Nut M10 x 1.25 x 11.8 - 14058621 | $0.79 | Special order, ships in 7-14 days |
| 8 | 14496624 | Ferrari Washer D. 10.50-21 x2 - 14496624 | $0.12 | Available, ships in 3-6 days |
| 9 | 102742 | Ferrari Nyloc Nut M10x1.25x10 - 102742 | $0.79 | Available, ships in 3-6 days |
| 10 | 12626224 | Ferrari Washer - 12626224 | $0.38 | Available, ships in 3-6 days |
| 11 | 267177 | Ferrari Clip D.20-21.5 - 267177 | $2.01 | Special order, ships in 7-14 days |
| 12 | 10280060 | Ferrari/Maserati Copper Washer - 10280060 | $1.93 | In stock |
| 13 | 229521A | Ferrari Steering Rack Boot Kit - 229521A | $129.90 | In stock |
| 14 | 250196 | Ferrari Tie Rod End - 250196 | $351.89 | In stock |
| 15 | 316543 | Ferrari Oil Delivery Pipe To Steering Box - 316543 | $664.78 | Special order, ships in 7-14 days |
| 16 | 265838 | Ferrari Power Steering Pipe Mounting Bracket - 265838 | $29.52 | Special order, ships in 7-14 days |
