Ferrari Monza SP2 — [MECHANICAL SYSTEM] - D.25.02 - FRONT SUSPENSION - ARMS (diagram 0076)

Exploded view of the [mechanical system] - d.25.02 - front suspension - arms on the Ferrari Monza SP2, with 60 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Monza SP2 [MECHANICAL SYSTEM] - D.25.02 - FRONT SUSPENSION - ARMS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
263033Ferrari Camber Spacer 1.0mm - 263033$7.19Special order, ships in 7-14 days
263034Ferrari Camber Spacer 1.5mm - 263034$7.19Special order, ships in 7-14 days
263036Ferrari Camber Spacer 2.5mm - 263036$10.25Special order, ships in 7-14 days
263038Ferrari Camber Spacer 3.5mm - 263038$10.25Special order, ships in 7-14 days
263039Ferrari Camber Spacer 4.0mm - 263039$10.25Special order, ships in 7-14 days
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
268896Ferrari LH Front Lower Arm Complete - 268896$1,695.11Available, ships in 3-6 days
248758Ferrari LH Front Upper Arm - 248758$1,297.30Special order, ships in 7-14 days
12575621Ferrari Nyloc Nut - 12575621SupersededOrder 102742 instead
268897Ferrari RH Front Lower Arm Complete - 268897$2,051.44Special order, ships in 7-14 days
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
126648Ferrari Washer - 126648SupersededOrder 14496624 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
1328040Ferrari Compl. RH Front Hub Carrier - 328040$3,737.37Special order, ships in 7-14 days
2328039Ferrari Compl. LH Front Hub Carrier - 328039$3,737.37Special order, ships in 7-14 days
3203795Ferrari Nut M14 x 1.5 - 203795$4.56Available, ships in 3-6 days
4241689Ferrari Spacer - 241689$14.62Special order, ships in 7-14 days
5259615Ferrari Sensor ABS Front - 259615$349.68Special order, ships in 7-14 days
7314494Ferrari RH Front Joint Bracket Complete - 314494$213.88Special order, ships in 7-14 days
8314493Ferrari LH Front Joint Bracket Complete - 314493$213.88Special order, ships in 7-14 days
9162606Ferrari Clip - 162606$2.82Available, ships in 3-6 days
1014040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
11268895Ferrari RH Front Lower Arm Complete - 268895$1,893.26Special order, ships in 7-14 days
12268894Ferrari LH Front Lower Arm Complete - 268894$1,893.26Special order, ships in 7-14 days
13264528Ferrari Threaded Rod 10x1.25 - 264528$7.63Available, ships in 3-6 days
1414496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
15104114Ferrari Nyloc Nut M10 x 1.25 x 12 - 104114$0.73Available, ships in 3-6 days
16238692Ferrari Camber Spacer 0.5mm - 238692$12.65Special order, ships in 7-14 days
16238693Ferrari Camber Spacer 1.0mm - 238693$10.25Special order, ships in 7-14 days
16238881Ferrari Camber Spacer 1.5mm - 238881$10.25Special order, ships in 7-14 days
16238694Ferrari Camber Spacer 2.0mm - 238694SupersededOrder 263035 instead
16263035Ferrari Camber Spacer 2.0mm - 263035$7.19Available, ships in 3-6 days
16238882Ferrari Camber Spacer 2.5mm - 238882$10.25Special order, ships in 7-14 days
16238883Ferrari Camber Spacer 3.0mm - 238883$10.25Available, ships in 3-6 days
16238884Ferrari Camber Spacer 3.5mm - 238884$10.25Special order, ships in 7-14 days
16238885Ferrari Camber Spacer 4.0mm - 238885$10.25Special order, ships in 7-14 days
17145854Ferrari Cable tie 200mm - 145854$0.57Available, ships in 3-6 days
18291864Ferrari ABS Cable Mounting Bracket - 291864$31.93Special order, ships in 7-14 days
1916296924Ferrari Screw M6 x 14 TE - 16296924$0.54Available, ships in 3-6 days
20248760Ferrari RH Front Upper Arm - 248760$1,303.14Available, ships in 3-6 days
20295789Ferrari RH Front Upper Arm - 295789SupersededOrder 248760 instead
21295788Ferrari LH Front Upper Arm - 295788$2,409.62Special order, ships in 7-14 days
22149807Ferrari Self-Locking Nut For Top And Bottom Ball Joints - 149807$2.13Available, ships in 3-6 days
2312646921Ferrari Washer - 12646921$0.92Available, ships in 3-6 days
2412646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
2412646821Ferrari Washer D.10 20-25x2 - 12646821$0.19Available, ships in 3-6 days
25320527Ferrari Compl. Front RH Motion Senso - 320527SupersededOrder 984043 instead
25984043Ferrari Compl. Front RH Motion Senso - 984043$327.81Special order, ships in 7-14 days
26320526Ferrari Compl. Front LH Motion Senso - 320526SupersededOrder 984042 instead
26984042Ferrari Compl. Front LH Motion Sensor - 984042$327.81Special order, ships in 7-14 days
27311876Ferrari Front RH Bracket - 311876$39.31Special order, ships in 7-14 days
28311875Ferrari Front LH Bracket - 311875$39.31Special order, ships in 7-14 days
29216973Ferrari Ball Joint D8 M6x1 - 216973$6.54Available, ships in 3-6 days
30320528Ferrari Potentiometer Tie-Rod - 320528$113.08Special order, ships in 7-14 days
30984041Ferrari Potentiometer Tie-Rod - 984041$194.22Special order, ships in 7-14 days
31231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
32217456Ferrari Screw 5X16 - 217456$0.59Available, ships in 3-6 days
33248790Ferrari Screw M12 x 1.25 x 50 - 248790$7.63Available, ships in 3-6 days
