Ferrari Portofino M — [VEHICLE TRIM] - E.14 - FRONT SHIELDS (diagram 0113)
Exploded view of the [vehicle trim] - e.14 - front shields on the Ferrari Portofino M, with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [VEHICLE TRIM] - E.14 - FRONT SHIELDS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0113.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 88972300 | Ferrari Compl. Centre Section Of Fro - 88972300 | Superseded | Order 88972200 instead | |
| 1 | 88972200 | Ferrari Compl. Centre Section Of Front Flat Undertray - 88972200 | $566.30 | Special order, ships in 7-14 days |
| 1 | 897682 | Ferrari Compl. Front Flat Undertray - 897682 | $517.04 | Special order, ships in 7-14 days |
| 2 | 88972400 | Ferrari LH Front Air Dam - 88972400 | $49.22 | Special order, ships in 7-14 days |
| 2 | 88972500 | Ferrari RH Front Air Dam - 88972500 | $49.22 | Special order, ships in 7-14 days |
| 3 | 82531200 | Ferrari Fixing Button - 82531200 | $3.26 | Available, ships in 3-6 days |
| 4 | 83442900 | Ferrari Body Screw - 83442900 | $1.51 | In stock |
| 5 | 80874300 | Ferrari Clip - 80874300 | $1.97 | Available, ships in 3-6 days |
| 6 | 84583500 | Ferrari Fastener clip - 84583500 | $2.59 | Available, ships in 3-6 days |
| 7 | 765764 | Ferrari Engine Subframe Front Undert - 765764 | $1,132.62 | Special order, ships in 7-14 days |
| 8 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
