Ferrari Purosangue — [VEHICLE TRIM] - E.10 - REAR LID SUBSTRUCTURE (diagram 0110)

Exploded view of the [vehicle trim] - e.10 - rear lid substructure on the Ferrari Purosangue, with 16 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Purosangue [VEHICLE TRIM] - E.10 - REAR LID SUBSTRUCTURE exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
11617624Ferrari Screw - 11617624SupersededOrder 16287224 instead
80415900Ferrari Screw - 80415900$32.60Available, ships in 3-6 days
242223Ferrari Spacer 0.5mm - 242223$4.98Special order, ships in 7-14 days
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
14496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
1955043452Ferrari Complete Tailgate - 955043452SupersededOrder 985820737 instead
1955062849Ferrari Complete Tailgate - 955062849$28,892.48Contact us to order
1985820737Ferrari Complete Tailgate - 985820737$21,656.33Contact us to order
216287224Ferrari Screw M8x25 - 16287224$0.82Available, ships in 3-6 days
312646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
4980674Ferrari Spacer 0.5mm - 980674$7.84Special order, ships in 7-14 days
4242224Ferrari Spacer 1.0mm - 242224$5.19Special order, ships in 7-14 days
484651000Ferrari Spacer 1.0mm - 84651000$6.96Special order, ships in 7-14 days
514507887Ferrari Plug. - 14507887$4.14Special order, ships in 7-14 days
