Ferrari Purosangue — [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS (diagram 0164)

Exploded view of the [vehicle trim] - e.47.09 - dashboard - fasteners on the Ferrari Purosangue, with 51 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Purosangue [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14304821Ferrari Allen Screw 6x55 - 14304821SupersededOrder 14304824 instead
12640624Ferrari Plain Washer 6mm - 12640624$0.31Available, ships in 3-6 days
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
86574400Ferrari Screw - 86574400SupersededOrder 86876500 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
11566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
106853Ferrari Spring Washer 10mm - 106853SupersededOrder 12601474 instead
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
10516873Ferrari Washer - 10516873SupersededOrder 12601474 instead
12601471Ferrari Washer - 12601471SupersededOrder 12601474 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
14496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
114308574Ferrari Allen Screw 10x1.25x90 - 14308574$7.40Available, ships in 3-6 days
212601474Ferrari Wavy Washer 10mm - 12601474$0.06Available, ships in 3-6 days
312646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
485834000Ferrari Screw M5 x 25 - 85834000$0.71Special order, ships in 7-14 days
667653400Ferrari Rivet - 67653400$0.38Special order, ships in 7-14 days
785833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
812624178Ferrari Washer D. 5.45 - 22 x 2 - 12624178$0.71Available, ships in 3-6 days
914418074Ferrari Screw M3x8 - 14418074$0.40Available, ships in 3-6 days
1012639901Ferrari Washer - 12639901$0.17Available, ships in 3-6 days
1186876500Ferrari Screw M4 x 12 TBEI - 86876500$7.84Special order, ships in 7-14 days
12935243Ferrari Screw TBFTX T20 M4 x 10 Nerinox - 935243$0.96Special order, ships in 7-14 days
13822994Ferrari Clip - 822994$6.75Special order, ships in 7-14 days
1413832611Ferrari Screw 6X45 - 13832611$1.94Available, ships in 3-6 days
1510523107Ferrari Washer - 10523107$5.44Available, ships in 3-6 days
1681045300Ferrari Screw 6x16 - 81045300$1.36Special order, ships in 7-14 days
1714059121Ferrari Nut M5 - 14059121$0.31Available, ships in 3-6 days
1815689201Ferrari Screw M3.5 x 25 - 15689201$1.92Available, ships in 3-6 days
1963343400Ferrari Screw 4x15 - 63343400$5.02Available, ships in 3-6 days
1915688801Ferrari Screw M3.5 x 13 - 15688801SupersededOrder 63343400 instead
20835458Ferrari Raymond Clip - 835458$0.82Special order, ships in 7-14 days
2114304824Ferrari Allen Screw 6x55 - 14304824$0.50Available, ships in 3-6 days
2212647024Ferrari Washer - 12647024$1.02Available, ships in 3-6 days
2212647624Ferrari Washer D 6.45-16x2 - 12647624$0.19Available, ships in 3-6 days
2385691900Ferrari Screw M5 x 8 TBFTX - 85691900$0.65Available, ships in 3-6 days
24958067Ferrari Screw - 958067$5.65Special order, ships in 7-14 days
25295423Ferrari Adhesive Foam - 295423$1.69Special order, ships in 7-14 days
2688822200Ferrari Screw 4 x 10 - 88822200$1.30Special order, ships in 7-14 days
2714496101Ferrari Washer - 14496101$0.12Available, ships in 3-6 days
2816286024Ferrari SCREW - 16286024$0.38Available, ships in 3-6 days
2985692300Ferrari Screw M5 x 20 TBFTX - 85692300$0.65Available, ships in 3-6 days
3085692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
3185692000Ferrari SCREW - 85692000$0.65Available, ships in 3-6 days
3186705000Ferrari Screw M5x10 TBFTX - 86705000$1.36Special order, ships in 7-14 days
32941666Ferrari Screw - 941666$3.03Special order, ships in 7-14 days
3514498804Ferrari Washer - 14498804SupersededOrder 14498824 instead
3514498824Ferrari Washer D. 6.4 - 16.3 - 14498824$0.27Available, ships in 3-6 days
3665752800Ferrari Screw M4 x 10 TBEI - 65752800$4.12Available, ships in 3-6 days
36986200Ferrari Torx Screw - 986200$0.44Special order, ships in 7-14 days

All Purosangue diagrams
