Ferrari Roma Spider — [MECHANICAL SYSTEM] - D.1 - ENGINE SUSPENSION BUSH (diagram 0048)
Exploded view of the [mechanical system] - d.1 - engine suspension bush on the Ferrari Roma Spider, with 19 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma Spider [MECHANICAL SYSTEM] - D.1 - ENGINE SUSPENSION BUSH exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma-spider/0048.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 121676 | Ferrari Bolt - 121676 | Superseded | Order 15971324 instead | |
| 123198 | Ferrari Bolt - 123198 | Superseded | Order 15971324 instead | |
| 959015 | Ferrari Complete LH Bracket - 959015 | $216.66 | Special order, ships in 7-14 days | |
| 959014 | Ferrari Complete RH Bracket - 959014 | $216.66 | Special order, ships in 7-14 days | |
| 304281 | Ferrari Heat Shield - 304281 | Superseded | Order 312024 instead | |
| 15971321 | Ferrari Screw - 15971321 | Superseded | Order 15971324 instead | |
| 14496609 | Ferrari Steel Washer - 14496609 | Superseded | Order 12646824 instead | |
| 12646824 | Ferrari Washer - 12646824 | Superseded | Order 14496624 instead | |
| 126648 | Ferrari Washer - 126648 | Superseded | Order 14496624 instead | |
| 14496601 | Ferrari Washer - 14496601 | Superseded | Order 12646824 instead | |
| 14496621 | Ferrari Washer - 14496621 | Superseded | Order 12646824 instead | |
| 1 | 303182 | Ferrari LH Bushing Complete - 303182 | $787.90 | Available, ships in 3-6 days |
| 1 | 303183 | Ferrari RH Bushing Complete - 303183 | $787.90 | Special order, ships in 7-14 days |
| 2 | 976929 | Ferrari Complete LH Bracket - 976929 | $216.66 | Special order, ships in 7-14 days |
| 2 | 976934 | Ferrari Complete RH Bracket - 976934 | $216.66 | Special order, ships in 7-14 days |
| 3 | 312024 | Ferrari Heat Shield - 312024 | $118.16 | Special order, ships in 7-14 days |
| 4 | 15971324 | Ferrari Bolt M10 x 1.25 - 15971324 | $3.26 | Available, ships in 3-6 days |
| 5 | 14496624 | Ferrari Washer D. 10.50-21 x2 - 14496624 | $0.12 | Available, ships in 3-6 days |
| 6 | 255271 | Ferrari Nut M12 x 1.25 x - 255271 | $2.59 | Available, ships in 3-6 days |
