Ferrari Roma Spider — [MECHANICAL SYSTEM] - D.27.02 - REAR SUSPENSION - ARMS (diagram 0080)

Exploded view of the [mechanical system] - d.27.02 - rear suspension - arms on the Ferrari Roma Spider, with 57 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Roma Spider [MECHANICAL SYSTEM] - D.27.02 - REAR SUSPENSION - ARMS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
314774Ferrari LH Rear Lower Arm Complete - 314774SupersededOrder 911176 instead
329243Ferrari LH Rear Lower Arm Complete - 329243SupersededOrder 911176 instead
12575621Ferrari Nyloc Nut - 12575621SupersededOrder 102742 instead
240662Ferrari Rear Support Lever Complete - 240662SupersededOrder 259687 instead
236783Ferrari Rear Suspension Link Arm - 236783SupersededOrder 259688 instead
259014Ferrari Rear Upper Arm - 259014SupersededOrder 259687 instead
314775Ferrari RH Rear Lower Arm Complete - 314775SupersededOrder 911175 instead
329244Ferrari RH Rear Lower Arm Complete - 329244SupersededOrder 911175 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
190870Ferrari Screw 6x14 - 190870$4.10Special order, ships in 7-14 days
764759Ferrari Sensore Di Spostam. Posterio - 764759$326.35Special order, ships in 7-14 days
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
12646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
126648Ferrari Washer - 126648SupersededOrder 14496624 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
1867720Ferrari Compl. LH Rear Hub Carrier - 867720$3,766.07Special order, ships in 7-14 days
1867728Ferrari Portamozzo Post Dx Cpl - 867728$3,766.07Special order, ships in 7-14 days
2336026Ferrari ABS Sensor - 336026$120.18Available, ships in 3-6 days
4896443Ferrari Compl. LH Rear Lower Arm - 896443SupersededOrder 911176 instead
4911176Ferrari Compl. LH Rear Lower Arm - 911176$1,745.74Special order, ships in 7-14 days
4896445Ferrari Compl. RH Rear Lower Arm - 896445SupersededOrder 911175 instead
4911175Ferrari Compl. RH Rear Lower Arm - 911175$1,745.74Special order, ships in 7-14 days
5238656Ferrari Special Screw TCEI M14 x 1.5 x 21 - 238656$45.87Available, ships in 3-6 days
6238063Ferrari Nut M14 x 1.x - 238063$7.40Available, ships in 3-6 days
7259688Ferrari Anti Rotation Linkage - 259688$295.03Special order, ships in 7-14 days
8238258Ferrari Screw M12 x 1.25 x 75 - 238258$63.37Special order, ships in 7-14 days
914507987Ferrari Rubber Plug - 14507987$3.85In stock
10104114Ferrari Nyloc Nut M10 x 1.25 x 12 - 104114$0.73Available, ships in 3-6 days
1114496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
12333339Ferrari Camber Adjustment Shim - 333339$7.19Special order, ships in 7-14 days
12333340Ferrari Camber Adjustment Shim - 333340$8.72Special order, ships in 7-14 days
12333341Ferrari Camber Adjustment Shim - 333341$11.12Available, ships in 3-6 days
12333342Ferrari Camber Adjustment Shim - 333342$13.30Special order, ships in 7-14 days
12333343Ferrari Camber Adjustment Shim - 333343$15.49Special order, ships in 7-14 days
12333338Ferrari Distanziale Regolaz. Camber - 333338$6.31Special order, ships in 7-14 days
12333344Ferrari Distanziale Regolaz. Camber - 333344$17.67Special order, ships in 7-14 days
12333345Ferrari Distanziale Regolaz. Camber - 333345$19.86Special order, ships in 7-14 days
13264528Ferrari Threaded Rod 10x1.25 - 264528$7.63Available, ships in 3-6 days
14216973Ferrari Ball Joint D8 M6x1 - 216973$6.54Available, ships in 3-6 days
15984046Ferrari Sensore Di Spostam. Posterio - 984046$327.81Special order, ships in 7-14 days
16820889Ferrari Rear LH Bracket for Motion Sensor - 820889$31.99Special order, ships in 7-14 days
16820890Ferrari Rear RH Bracket for Motion Sensor - 820890$31.99Special order, ships in 7-14 days
17231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
1816284934Ferrari Screw - 16284934$1.61Available, ships in 3-6 days
1816284927Ferrari Screw 5x10 - 16284927SupersededOrder 16284934 instead
19250657Ferrari Screw M6 x 14 TBTX - 250657$13.36Available, ships in 3-6 days
20338394Ferrari LH Rear Joint Bracket - 338394$41.76Special order, ships in 7-14 days
20338395Ferrari RH Rear Joint Bracket - 338395$41.76Special order, ships in 7-14 days
2114040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
22245161Ferrari Tie Rod Complete - 245161$301.17Available, ships in 3-6 days
2315541434Ferrari Screw 12x1.25x80 - 15541434$4.12Special order, ships in 7-14 days
2414496721Ferrari Washer - 14496721$0.19Special order, ships in 7-14 days
25203666Ferrari Nut - 203666$1.80Available, ships in 3-6 days
26259687Ferrari Rear Upper Arm Complete - 259687$688.45Special order, ships in 7-14 days
2712646821Ferrari Washer D.10 20-25x2 - 12646821$0.19Available, ships in 3-6 days

All Roma Spider diagrams
