Ferrari Roma — [MECHANICAL SYSTEM] - D.27.02 - REAR SUSPENSION - ARMS (diagram 0080)

Exploded view of the [mechanical system] - d.27.02 - rear suspension - arms on the Ferrari Roma, with 58 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Roma [MECHANICAL SYSTEM] - D.27.02 - REAR SUSPENSION - ARMS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
314774Ferrari LH Rear Lower Arm Complete - 314774SupersededOrder 911176 instead
329243Ferrari LH Rear Lower Arm Complete - 329243SupersededOrder 911176 instead
12575621Ferrari Nyloc Nut - 12575621SupersededOrder 102742 instead
240662Ferrari Rear Support Lever Complete - 240662SupersededOrder 259687 instead
236783Ferrari Rear Suspension Link Arm - 236783SupersededOrder 259688 instead
259014Ferrari Rear Upper Arm - 259014SupersededOrder 259687 instead
314775Ferrari RH Rear Lower Arm Complete - 314775SupersededOrder 911175 instead
329244Ferrari RH Rear Lower Arm Complete - 329244SupersededOrder 911175 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
190870Ferrari Screw 6x14 - 190870$4.10Special order, ships in 7-14 days
764759Ferrari Sensore Di Spostam. Posterio - 764759$326.35Special order, ships in 7-14 days
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
12646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
126648Ferrari Washer - 126648SupersededOrder 14496624 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
1867720Ferrari Compl. LH Rear Hub Carrier - 867720$3,766.07Special order, ships in 7-14 days
1867728Ferrari Portamozzo Post Dx Cpl - 867728$3,766.07Special order, ships in 7-14 days
2336026Ferrari ABS Sensor - 336026$120.18Available, ships in 3-6 days
4896443Ferrari Compl. LH Rear Lower Arm - 896443SupersededOrder 911176 instead
4911176Ferrari Compl. LH Rear Lower Arm - 911176$1,745.74Special order, ships in 7-14 days
4896445Ferrari Compl. RH Rear Lower Arm - 896445SupersededOrder 911175 instead
4911175Ferrari Compl. RH Rear Lower Arm - 911175$1,745.74Special order, ships in 7-14 days
5238656Ferrari Special Screw TCEI M14 x 1.5 x 21 - 238656$45.87Available, ships in 3-6 days
6238063Ferrari Nut M14 x 1.x - 238063$7.40Available, ships in 3-6 days
7259688Ferrari Anti Rotation Linkage - 259688$295.03Special order, ships in 7-14 days
8238258Ferrari Screw M12 x 1.25 x 75 - 238258$63.37Special order, ships in 7-14 days
9222956Ferrari Compensator Ring 24x12 - 222956$20.76Available, ships in 3-6 days
1014507987Ferrari Rubber Plug - 14507987$3.85In stock
11104114Ferrari Nyloc Nut M10 x 1.25 x 12 - 104114$0.73Available, ships in 3-6 days
1214496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
13333339Ferrari Camber Adjustment Shim - 333339$7.19Special order, ships in 7-14 days
13333340Ferrari Camber Adjustment Shim - 333340$8.72Special order, ships in 7-14 days
13333341Ferrari Camber Adjustment Shim - 333341$11.12Available, ships in 3-6 days
13333342Ferrari Camber Adjustment Shim - 333342$13.30Special order, ships in 7-14 days
13333343Ferrari Camber Adjustment Shim - 333343$15.49Special order, ships in 7-14 days
13333338Ferrari Distanziale Regolaz. Camber - 333338$6.31Special order, ships in 7-14 days
13333344Ferrari Distanziale Regolaz. Camber - 333344$17.67Special order, ships in 7-14 days
13333345Ferrari Distanziale Regolaz. Camber - 333345$19.86Special order, ships in 7-14 days
14264528Ferrari Threaded Rod 10x1.25 - 264528$7.63Available, ships in 3-6 days
15216973Ferrari Ball Joint D8 M6x1 - 216973$6.54Available, ships in 3-6 days
16984046Ferrari Sensore Di Spostam. Posterio - 984046$327.81Special order, ships in 7-14 days
17820889Ferrari Rear LH Bracket for Motion Sensor - 820889$31.99Special order, ships in 7-14 days
17820890Ferrari Rear RH Bracket for Motion Sensor - 820890$31.99Special order, ships in 7-14 days
18231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
1916284934Ferrari Screw - 16284934$1.61Available, ships in 3-6 days
1916284927Ferrari Screw 5x10 - 16284927SupersededOrder 16284934 instead
20250657Ferrari Screw M6 x 14 TBTX - 250657$13.36Available, ships in 3-6 days
21338394Ferrari LH Rear Joint Bracket - 338394$41.76Special order, ships in 7-14 days
21338395Ferrari RH Rear Joint Bracket - 338395$41.76Special order, ships in 7-14 days
2214040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
23245161Ferrari Tie Rod Complete - 245161$301.17Available, ships in 3-6 days
2415541434Ferrari Screw 12x1.25x80 - 15541434$4.12Special order, ships in 7-14 days
2514496721Ferrari Washer - 14496721$0.19Special order, ships in 7-14 days
26203666Ferrari Nut - 203666$1.80Available, ships in 3-6 days
27259687Ferrari Rear Upper Arm Complete - 259687$688.45Special order, ships in 7-14 days
2812646821Ferrari Washer D.10 20-25x2 - 12646821$0.19Available, ships in 3-6 days

All Roma diagrams
