Ferrari Roma — [VEHICLE TRIM] - E.14 - FRONT SHIELDS (diagram 0113)
Exploded view of the [vehicle trim] - e.14 - front shields on the Ferrari Roma, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma [VEHICLE TRIM] - E.14 - FRONT SHIELDS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma/0113.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 897682 | Ferrari Compl. Front Flat Undertray - 897682 | $517.04 | Special order, ships in 7-14 days |
| 2 | 88972400 | Ferrari LH Front Air Dam - 88972400 | $49.22 | Special order, ships in 7-14 days |
| 2 | 88972500 | Ferrari RH Front Air Dam - 88972500 | $49.22 | Special order, ships in 7-14 days |
| 3 | 82531200 | Ferrari Fixing Button - 82531200 | $3.26 | Available, ships in 3-6 days |
| 4 | 83442900 | Ferrari Body Screw - 83442900 | $1.51 | In stock |
| 5 | 80874300 | Ferrari Clip - 80874300 | $1.97 | Available, ships in 3-6 days |
| 6 | 962736 | Ferrari Fondo Ant. Sottotelaio Motor - 962736 | $1,829.08 | Special order, ships in 7-14 days |
| 7 | 967498 | Ferrari LH Front Dam - Behind Wheel - 967498 | $174.80 | Special order, ships in 7-14 days |
| 7 | 967499 | Ferrari RH Front Dam - Behind Wheel - 967499 | $174.80 | Special order, ships in 7-14 days |
| 8 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 9 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 10 | 12643701 | Ferrari Flat Washer - 12643701 | $0.12 | Available, ships in 3-6 days |
| 11 | 84583500 | Ferrari Fastener clip - 84583500 | $2.59 | Available, ships in 3-6 days |
