Ferrari Roma — [VEHICLE TRIM] - E.59 - EXTERNAL LATERAL TRIM (diagram 0172)
Exploded view of the [vehicle trim] - e.59 - external lateral trim on the Ferrari Roma, with 31 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Roma [VEHICLE TRIM] - E.59 - EXTERNAL LATERAL TRIM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/roma/0172.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 15896214 | Ferrari Nut M6 x 5 - 15896214 | Superseded | Order 14039614 instead | |
| 1 | 70007117 | Ferrari Compl. LH Sill Trim Panel - 70007117 | $26,908.93 | Contact us to order |
| 1 | 70007116 | Ferrari Compl. RH Sill Trim Panel - 70007116 | $26,908.93 | Contact us to order |
| 1 | 895578 | Ferrari Complete LH Sill Trim Panel - 895578 | $16,842.99 | Contact us to order |
| 1 | 899365 | Ferrari Complete LH Sill Trim Panel - 899365 | $342.66 | Special order, ships in 7-14 days |
| 1 | 927060 | Ferrari Complete LH Sill Trim Panel - 927060 | Price on request | Special order, ships in 7-14 days |
| 1 | 895603 | Ferrari Complete RH Sill Trim Panel - 895603 | $16,842.99 | Contact us to order |
| 1 | 899364 | Ferrari Complete RH Sill Trim Panel - 899364 | $342.66 | Special order, ships in 7-14 days |
| 1 | 927061 | Ferrari Complete RH Sill Trim Panel - 927061 | $16,842.99 | Contact us to order |
| 2 | 965387 | Ferrari Compl. Kickplate - 965387 | $393.38 | Special order, ships in 7-14 days |
| 2 | 981164 | Ferrari Compl. Kickplate In Carbon - 981164 | $1,826.53 | Special order, ships in 7-14 days |
| 3 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 4 | 80874300 | Ferrari Clip - 80874300 | $1.97 | Available, ships in 3-6 days |
| 5 | 14115680 | Ferrari Plastic Screw Plug - 14115680 | $0.12 | Available, ships in 3-6 days |
| 6 | 792394 | Ferrari Screw TE M6 x 18 - 792394 | $0.84 | Available, ships in 3-6 days |
| 7 | 899370 | Ferrari Supporto Post Dx - 899370 | $20.30 | Special order, ships in 7-14 days |
| 7 | 899375 | Ferrari Supporto Post Sx - 899375 | $20.30 | Special order, ships in 7-14 days |
| 8 | 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days |
| 9 | 82672700 | Ferrari Fixing Clip - 82672700 | $1.67 | Available, ships in 3-6 days |
| 9 | 66092400 | Ferrari Trim Clip - 66092400 | $0.25 | In stock |
| 10 | 88962300 | Ferrari LH Rear Dam - 88962300 | $34.44 | Special order, ships in 7-14 days |
| 10 | 88962400 | Ferrari RH Rear Dam - 88962400 | $34.44 | Special order, ships in 7-14 days |
| 11 | 83442900 | Ferrari Body Screw - 83442900 | $1.51 | In stock |
| 12 | 68888400 | Ferrari Rivet - 68888400 | $5.04 | Available, ships in 3-6 days |
| 13 | 15538777 | Ferrari Screw 8x13 - 15538777 | $0.34 | Available, ships in 3-6 days |
| 14 | 985792112 | Ferrari LH Roof Gutter Moulding - 985792112 | $1,101.47 | Special order, ships in 7-14 days |
| 14 | 985792113 | Ferrari RH Roof Gutter Moulding - 985792113 | $1,101.47 | Special order, ships in 7-14 days |
| 15 | 794274 | Ferrari Roof Gutter Moulding Seal - 794274 | $32.60 | Special order, ships in 7-14 days |
| 16 | 899372 | Ferrari Double-Sided Adhesive Spacer - 899372 | $75.86 | Special order, ships in 7-14 days |
| 17 | 833298 | Ferrari LH Front Fender Cover - 833298 | $41.30 | Special order, ships in 7-14 days |
| 17 | 833299 | Ferrari RH Front Fender Cover - 833299 | $41.30 | Special order, ships in 7-14 days |
