Ferrari SF90 Spider — [MECHANICAL SYSTEM] - D.25.02 - FRONT SUSPENSION - ARMS (diagram 0076)

Exploded view of the [mechanical system] - d.25.02 - front suspension - arms on the Ferrari SF90 Spider, with 58 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari SF90 Spider [MECHANICAL SYSTEM] - D.25.02 - FRONT SUSPENSION - ARMS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
238693Ferrari Camber Spacer 1.0mm - 238693$10.25Special order, ships in 7-14 days
238881Ferrari Camber Spacer 1.5mm - 238881$10.25Special order, ships in 7-14 days
238694Ferrari Camber Spacer 2.0mm - 238694SupersededOrder 263035 instead
238882Ferrari Camber Spacer 2.5mm - 238882$10.25Special order, ships in 7-14 days
238884Ferrari Camber Spacer 3.5mm - 238884$10.25Special order, ships in 7-14 days
238885Ferrari Camber Spacer 4.0mm - 238885$10.25Special order, ships in 7-14 days
12575621Ferrari Nyloc Nut - 12575621SupersededOrder 102742 instead
320528Ferrari Potentiometer Tie-Rod - 320528$113.08Special order, ships in 7-14 days
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
765409Ferrari Sensore Di Spostam. Ant Cpl - 765409SupersededOrder 984050 instead
14496609Ferrari Steel Washer - 14496609SupersededOrder 12646824 instead
126648Ferrari Washer - 126648SupersededOrder 14496624 instead
14496601Ferrari Washer - 14496601SupersededOrder 12646824 instead
14496621Ferrari Washer - 14496621SupersededOrder 12646824 instead
1862453Ferrari Compl. LH Front Hub Carrier - 862453$3,760.79Special order, ships in 7-14 days
1862457Ferrari Compl. RH Front Hub Carrier - 862457$3,760.79Special order, ships in 7-14 days
2896440Ferrari Complete Lower LH Front Arm - 896440$1,920.19Special order, ships in 7-14 days
2896441Ferrari Complete Lower RH Front Arm - 896441$1,920.19Special order, ships in 7-14 days
3203795Ferrari Nut M14 x 1.5 - 203795$4.56Available, ships in 3-6 days
4241689Ferrari Spacer - 241689$14.62Special order, ships in 7-14 days
5104114Ferrari Nyloc Nut M10 x 1.25 x 12 - 104114$0.73Available, ships in 3-6 days
614496624Ferrari Washer D. 10.50-21 x2 - 14496624$0.12Available, ships in 3-6 days
7264528Ferrari Threaded Rod 10x1.25 - 264528$7.63Available, ships in 3-6 days
8263033Ferrari Camber Spacer 1.0mm - 263033$7.19Special order, ships in 7-14 days
8263034Ferrari Camber Spacer 1.5mm - 263034$7.19Special order, ships in 7-14 days
8263035Ferrari Camber Spacer 2.0mm - 263035$7.19Available, ships in 3-6 days
8263036Ferrari Camber Spacer 2.5mm - 263036$10.25Special order, ships in 7-14 days
8238883Ferrari Camber Spacer 3.0mm - 238883$10.25Available, ships in 3-6 days
8263037Ferrari Camber Spacer 3.0mm - 263037SupersededOrder 238883 instead
8263038Ferrari Camber Spacer 3.5mm - 263038$10.25Special order, ships in 7-14 days
8263039Ferrari Camber Spacer 4.0mm - 263039$10.25Special order, ships in 7-14 days
9102825Ferrari Locking Suspension Nut - 102825$1.10In stock
10283959Ferrari Adjustment Plate - 283959$51.67Special order, ships in 7-14 days
10283960Ferrari Adjustment Plate 1.0mm - 283960$66.35Special order, ships in 7-14 days
10283961Ferrari Adjustment Plate 1.5mm - 283961$66.35Special order, ships in 7-14 days
10283954Ferrari Adjustment Plate 2.0mm - 283954$66.35Special order, ships in 7-14 days
10283955Ferrari Adjustment Plate 2.5mm - 283955$66.35Special order, ships in 7-14 days
10283956Ferrari Adjustment Plate 3.0mm - 283956$66.35Special order, ships in 7-14 days
10283957Ferrari Adjustment Plate 3.5mm - 283957$66.35Special order, ships in 7-14 days
10283958Ferrari Adjustment Plate 4.0mm - 283958$66.35Special order, ships in 7-14 days
11896438Ferrari Barra Filettata M12X1.25 L.6 - 896438$7.63Special order, ships in 7-14 days
1213507434Ferrari Flat Washer 12 - 13507434$2.59Special order, ships in 7-14 days
13331628Ferrari Complete LH Front Upper Arm - 331628$1,278.55Special order, ships in 7-14 days
13331629Ferrari Complete RH Front Upper Arm - 331629$1,352.32Special order, ships in 7-14 days
14149807Ferrari Self-Locking Nut For Top And Bottom Ball Joints - 149807$2.13Available, ships in 3-6 days
1512646824Ferrari Washer - 12646824SupersededOrder 14496624 instead
1512646821Ferrari Washer D.10 20-25x2 - 12646821$0.19Available, ships in 3-6 days
16216973Ferrari Ball Joint D8 M6x1 - 216973$6.54Available, ships in 3-6 days
17984050Ferrari Sensore Di Spostam. Ant Cpl - 984050$327.81Special order, ships in 7-14 days
18340273Ferrari Ball Joint - 340273$88.49Special order, ships in 7-14 days
19814254Ferrari Nut - 814254$1.23Special order, ships in 7-14 days
20984041Ferrari Potentiometer Tie-Rod - 984041$194.22Special order, ships in 7-14 days
21831077Ferrari Motion Sensor Fastener Bracket - 831077$34.40Special order, ships in 7-14 days
21860788Ferrari RH Front Bracket - 860788$34.40Special order, ships in 7-14 days
2216284934Ferrari Screw - 16284934$1.61Available, ships in 3-6 days
2216284927Ferrari Screw 5x10 - 16284927SupersededOrder 16284934 instead
23231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
24336025Ferrari ABS Sensor - 336025$120.18Special order, ships in 7-14 days
