Ferrari 12 Cilindri Spider — [MECHANICAL SYSTEM] - D.02 - ENGINE FUEL DELIVERY PIPES (diagram 0049)
Exploded view of the [mechanical system] - d.02 - engine fuel delivery pipes on the Ferrari 12 Cilindri Spider, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri Spider [MECHANICAL SYSTEM] - D.02 - ENGINE FUEL DELIVERY PIPES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri-spider/0049.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 293146 | Ferrari Clip - 293146 | $2.09 | Special order, ships in 7-14 days | |
| 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days | |
| 1 | 988044 | Ferrari LOW PRESSURE FUEL PIPE - 988044 | Price on request | Contact us for price and availability |
| 2 | 895385 | Ferrari Bracket - 895385 | $76.19 | Special order, ships in 7-14 days |
| 3 | 969197 | Ferrari Bracket - 969197 | $44.24 | Special order, ships in 7-14 days |
| 4 | 67190200 | Ferrari Bracket With Sheath 14mm - 67190200 | $3.91 | Special order, ships in 7-14 days |
| 5 | 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days |
| 5 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
| 6 | 257273 | Ferrari Clip D. 14-16 - 257273 | $2.59 | Special order, ships in 7-14 days |
