Ferrari 12 Cilindri Spider — [MECHANICAL SYSTEM] - D.09 - ENGINE OIL RADIATOR AND TANK (diagram 0058)

Exploded view of the [mechanical system] - d.09 - engine oil radiator and tank on the Ferrari 12 Cilindri Spider, with 72 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 12 Cilindri Spider [MECHANICAL SYSTEM] - D.09 - ENGINE OIL RADIATOR AND TANK exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14305721Ferrari Allen Bolt 6x14 - 14305721SupersededOrder 248334 instead
14305724Ferrari Allen Screw TCEI M6 x 14 - 14305724$0.34Available, ships in 3-6 days
10902121Ferrari Bolt - 10902121SupersededOrder 10902124 instead
95880306Ferrari Bolt 6x16 - 95880306SupersededOrder 10902124 instead
743995Ferrari Compl. Engine Oil Tank - 743995Price on requestContact us for price and availability
257823Ferrari Electric Fan Complete - 257823SupersededOrder 277070 instead
103373Ferrari Nut - 103373SupersededOrder 102948 instead
12774221Ferrari Nut - 12774221SupersededOrder 102948 instead
125519Ferrari Nyloc Nut - 125519SupersededOrder 102948 instead
12574221Ferrari Nyloc Nut - 12574221SupersededOrder 102948 instead
12601224Ferrari Washer - 12601224SupersededOrder 12601274 instead
12605370Ferrari Washer - 12605370SupersededOrder 12601274 instead
12605371Ferrari Washer - 12605371SupersededOrder 12601274 instead
12643711Ferrari Washer - 12643711SupersededOrder 12643724 instead
12643721Ferrari Washer - 12643721SupersededOrder 12643724 instead
14499301Ferrari Washer - 14499301SupersededOrder 12643724 instead
680232Ferrari Washer - 680232SupersededOrder 12601274 instead
12605374Ferrari Wavy Washer - 12605374SupersededOrder 12601274 instead
10257060Ferrari/Maserati Copper Washer - 10257060$1.10In stock
155026871Ferrari Compl. Engine Oil Tank - 55026871$8,355.26Special order, ships in 7-14 days
155031061Ferrari Serbatoio Olio Motore Cpl Us - 55031061Price on requestContact us to order
2871237Ferrari ENGINE OIL LEVEL SENSOR - 871237$415.25Special order, ships in 7-14 days
3842657Ferrari Oil Tank Pickup - 842657$713.04Special order, ships in 7-14 days
4100332Ferrari Sump Filter - 100332$37.13Available, ships in 3-6 days
5125521Ferrari/Maserati Oil Tank O-Ring - 125521$13.20In stock
610300711Ferrari Threaded Drain Plug - 10300711$4.59In stock
710261460Ferrari Copper Washer 16x24x1.5 - 10261460$0.63Available, ships in 3-6 days
8102948Ferrari Nyloc Nut M6 x 8 - 102948$0.46Available, ships in 3-6 days
912601274Ferrari Wavy Washer 6mm - 12601274$1.04Available, ships in 3-6 days
1011500524Ferrari Stud Bolt M6 x 9 Gambo 22 - 11500524$0.73Available, ships in 3-6 days
11842695Ferrari Cap Compl. With Dipstick - 842695$590.08Special order, ships in 7-14 days
12842627Ferrari Front Fastener Bracket - 842627$115.54Special order, ships in 7-14 days
13971623Ferrari Screw - 971623$4.56Special order, ships in 7-14 days
1412643724Ferrari/Maserati Washer - 12643724$0.20In stock
15103549Ferrari Grommet - 103549$2.80In stock
16149707Ferrari Spacer - 149707$2.13Available, ships in 3-6 days
17792394Ferrari Screw TE M6 x 18 - 792394$0.84Available, ships in 3-6 days
18842704Ferrari Centre Tank Mounting Bracket - 842704$95.87Special order, ships in 7-14 days
1910902124Ferrari Screw - 10902124$0.29In stock
20812381Ferrari Upper Tank Mounting Bracket - 812381$152.41Special order, ships in 7-14 days
2155055105Ferrari Head Delivery Pipe From Tank - 55055105$1,081.84Special order, ships in 7-14 days
21820144Ferrari Head Delivery Pipe From Tank - 820144$1,003.57Special order, ships in 7-14 days
22842720Ferrari Head Vapour Recovery Pipe - 842720$132.75Special order, ships in 7-14 days
23842712Ferrari Blow-By Pipe From Tank To Di - 842712$218.81Special order, ships in 7-14 days
24987510Ferrari Blow-By Pipe From Disconnect - 987510$491.74Special order, ships in 7-14 days
25822843Ferrari Rubber Pipe - 822843$67.73Special order, ships in 7-14 days
26822171Ferrari Rubber Pipe - 822171$159.52Special order, ships in 7-14 days
27842721Ferrari Rubber Pipe - 842721$63.37Special order, ships in 7-14 days
28171406Ferrari Hose Retaining Clip - 171406$1.42Available, ships in 3-6 days
2913432570Ferrari Collar - 13432570$2.82Special order, ships in 7-14 days
30842722Ferrari Mounting Bracket - 842722$56.52Special order, ships in 7-14 days
3114574287Ferrari Pipe Clip - 14574287$16.01Available, ships in 3-6 days
32270085Ferrari Clip - 270085$3.68Available, ships in 3-6 days
33258855Ferrari 3-Way Union - 258855$87.40Special order, ships in 7-14 days
3410441890Ferrari P Clip Bracket With Sheath D22 - 10441890$1.17Available, ships in 3-6 days
3510441390Ferrari P clip Bracket With Sheath D.12 - 10441390$1.02Available, ships in 3-6 days
36248334Ferrari Screw M6 x 16 TCEI - 248334$1.25Available, ships in 3-6 days
37262559Ferrari Clip - 262559$1.78Available, ships in 3-6 days
3810450690Ferrari P Clip Bracket With Sheath - 10450690$1.25Available, ships in 3-6 days
39844495Ferrari CLIP - 844495Price on requestContact us for price and availability
40844502Ferrari Clip - 844502$11.35Special order, ships in 7-14 days
41842718Ferrari Oil Radiator - 842718$1,721.15Special order, ships in 7-14 days
42277070Ferrari Electric Fan Complete - 277070$467.15Special order, ships in 7-14 days
4355002621Ferrari Compl. LH Oil Radiator Mount - 55002621$181.93Special order, ships in 7-14 days
4355002618Ferrari Compl. RH Oil Radiator Mount - 55002618$181.93Special order, ships in 7-14 days
44138926Ferrari Rubber Spacer - 138926$8.72Available, ships in 3-6 days
4510718011Ferrari Nut - 10718011$0.13Available, ships in 3-6 days
4613577724Ferrari Washer - 13577724$3.68Special order, ships in 7-14 days
4784093700Ferrari Clip - 84093700$2.82Special order, ships in 7-14 days
48832637Ferrari Upper Oil Radiator Fastener - 832637$86.04Special order, ships in 7-14 days
4981564500Ferrari Screw - 81564500$7.84Available, ships in 3-6 days
50231616Ferrari Screw 6x14 - 231616$0.57Available, ships in 3-6 days

All 12 Cilindri Spider diagrams
