Ferrari 12 Cilindri Spider — [ELECTRICAL SYSTEM] - F.12 - DCT GEARBOX SYSTEM (diagram 0187)

Exploded view of the [electrical system] - f.12 - dct gearbox system on the Ferrari 12 Cilindri Spider, with 15 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari 12 Cilindri Spider [ELECTRICAL SYSTEM] - F.12 - DCT GEARBOX SYSTEM exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14305721Ferrari Allen Bolt 6x14 - 14305721SupersededOrder 248334 instead
14305724Ferrari Allen Screw TCEI M6 x 14 - 14305724$0.34Available, ships in 3-6 days
834197Ferrari Buffer Battery - 834197$678.46Special order, ships in 7-14 days
14039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
291225Ferrari P clip Bracket With Sheath - 291225$7.86Special order, ships in 7-14 days
248334Ferrari Screw M6 x 16 TCEI - 248334$1.25Available, ships in 3-6 days
1959281Ferrari DCT Cable - 959281$1,253.96Special order, ships in 7-14 days
214059111Ferrari Flanged Nut M5 - 14059111$0.08Available, ships in 3-6 days
214039511Ferrari Nut - 14039511$0.54Available, ships in 3-6 days
3863817Ferrari Buffer Battery - 863817$677.50Special order, ships in 7-14 days
4855811Ferrari DCT Gearbox ECU - Marelli - 855811$2,817.08Special order, ships in 7-14 days
5231616Ferrari Screw 6x14 - 231616$0.57Available, ships in 3-6 days
610441490Ferrari/Maserati Retaining Clip - 10441490$1.35In stock
710442290Ferrari P Clip Bracket With Sheath - 10442290$1.42Special order, ships in 7-14 days
8179309Ferrari ADHESIVE FOAM - 179309$8.28Available, ships in 3-6 days

All 12 Cilindri Spider diagrams
