Ferrari 12 Cilindri — [ENGINE] - B.18 - FUEL PUMPS (diagram 0023)
Exploded view of the [engine] - b.18 - fuel pumps on the Ferrari 12 Cilindri, with 19 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 12 Cilindri [ENGINE] - B.18 - FUEL PUMPS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/12-cilindri/0023.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 331303 | Ferrari LH Fuel Pump - 331303 | Price on request | Contact us for price and availability | |
| 793016 | Ferrari LH Fuel Pump - 793016 | $1,087.88 | Special order, ships in 7-14 days | |
| 331302 | Ferrari RH Fuel Pump - 331302 | Superseded | Order 815913 instead | |
| 793015 | Ferrari RH Fuel Pump - 793015 | Superseded | Order 815913 instead | |
| 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days | |
| 1 | 815913 | Ferrari RH Fuel Pump - 815913 | $1,092.79 | Special order, ships in 7-14 days |
| 2 | 815914 | Ferrari LH Fuel Pump - 815914 | $1,092.79 | Special order, ships in 7-14 days |
| 3 | 881951 | Ferrari RH Gdi Pump Soundproofing - 881951 | $127.82 | Special order, ships in 7-14 days |
| 4 | 881952 | Ferrari LH Gdi Pump Soundproofing - 881952 | $127.82 | Special order, ships in 7-14 days |
| 5 | 331787 | Ferrari HIGH PRESSURE PUMP CAM FOLLOWER - 331787 | $105.70 | Special order, ships in 7-14 days |
| 6 | 14306434 | Ferrari Screw M8x25 - 14306434 | $0.71 | Special order, ships in 7-14 days |
| 7 | 12638524 | Ferrari Flat Washer 8.15x15x1.5 - 12638524 | $0.12 | Available, ships in 3-6 days |
| 8 | 916817 | Ferrari RH Fuel Pipe - 916817 | $240.94 | Special order, ships in 7-14 days |
| 9 | 916819 | Ferrari LH Fuel Pipe - 916819 | $243.40 | Special order, ships in 7-14 days |
| 10 | 836236 | Ferrari Bracket - 836236 | $71.28 | Special order, ships in 7-14 days |
| 11 | 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days |
| 12 | 763134 | Ferrari Fuel Pump Seal - 763134 | $6.96 | Special order, ships in 7-14 days |
