Ferrari 296 GTB — [ENGINE] - B.16 - IGNITION COIL SPARK PLUGS AND SENSORS (diagram 0021)
Exploded view of the [engine] - b.16 - ignition coil spark plugs and sensors on the Ferrari 296 GTB, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 296 GTB [ENGINE] - B.16 - IGNITION COIL SPARK PLUGS AND SENSORS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/296-gtb/0021.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14305721 | Ferrari Allen Bolt 6x14 - 14305721 | Superseded | Order 248334 instead | |
| 14305724 | Ferrari Allen Screw TCEI M6 x 14 - 14305724 | $0.34 | Available, ships in 3-6 days | |
| 231616 | Ferrari Screw 6x14 - 231616 | $0.57 | Available, ships in 3-6 days | |
| 1 | 800390 | Ferrari Ignition Coil - 800390 | Superseded | Order 889547 instead |
| 1 | 889547 | Ferrari Ignition Coil - 889547 | $270.44 | Available, ships in 3-6 days |
| 2 | 808693 | Ferrari Spark Plug - 808693 | $38.00 | In stock |
| 3 | 231620 | Ferrari/Maserati Screw - 231620 | $0.58 | In stock |
| 4 | 935184 | Ferrari Bush - 935184 | $13.09 | Special order, ships in 7-14 days |
| 5 | 334070 | Ferrari Gommino Silic.Antiv.A 3 Risa - 334070 | $1.17 | Special order, ships in 7-14 days |
| 6 | 935179 | Ferrari Phase Sensor Pg 3.9 M - 935179 | $117.47 | Available, ships in 3-6 days |
| 7 | 248334 | Ferrari Screw M6 x 16 TCEI - 248334 | $1.25 | Available, ships in 3-6 days |
| 8 | 922805 | Ferrari RPM Sensor - 922805 | $187.93 | Available, ships in 3-6 days |
| 9 | 231618 | Ferrari Allen Head Screw M6x20 TCEI - 231618 | $0.57 | Available, ships in 3-6 days |
