Ferrari 365 GTB4 (Daytona) — Front Lamp Motor (diagram 225A)
Exploded view of the front lamp motor on the Ferrari 365 GTB4 (Daytona), with 36 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
/225A.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 40089401 | Ferrari RH Head Lamp Motor - 40089401 | Price on request | Contact us for price and availability |
| 1 | 40089500 | Ferrari LH Head Lamp Motor - 40089500 | Superseded | Order 172535 instead |
| 2 | 30044408 | Ferrari Bracket - 30044408 | $21.41 | Available, ships in 3-6 days |
| 3 | 12601274 | Ferrari Wavy Washer 6mm - 12601274 | $1.04 | Available, ships in 3-6 days |
| 3 | 12605370 | Ferrari Washer - 12605370 | Superseded | Order 12601274 instead |
| 4 | 10902124 | Ferrari Screw - 10902124 | $0.29 | In stock |
| 4 | 10902111 | Ferrari Bolt - 10902111 | Superseded | Order 10902124 instead |
| 5 | 40213902 | Ferrari Pivot - 40213902 | $49.60 | Available, ships in 3-6 days |
| 7 | 11087974 | Ferrari Circlip - 11087974 | $0.38 | Available, ships in 3-6 days |
| 7 | 11087975 | Ferrari Circlip - 11087975 | Superseded | Order 11087974 instead |
| 8 | 94724 | Ferrari Washer - 94724 | Superseded | Order 100812 instead |
| 8 | 100812 | Ferrari Washer - 100812 | $1.99 | Available, ships in 3-6 days |
| 13 | 16100824 | Ferrari/Maserati Nut - 16100824 | $0.30 | In stock |
| 13 | 16100811 | Ferrari Nut 8x6.5mm - 16100811 | Superseded | Order 16100824 instead |
| 14 | 30152706 | Ferrari Support H/L Pop Up - 30152706 | Price on request | Contact us for price and availability |
| 15 | 10615670 | Ferrari Washer - 10615670 | Superseded | Order 12601374 instead |
| 15 | 12601374 | Ferrari Wavy Washer 8mm - 12601374 | $3.12 | Available, ships in 3-6 days |
| 16 | 400877 | Ferrari Pin - 400877 | $76.09 | Available, ships in 3-6 days |
| 17 | 30044101 | Ferrari Bracket - 30044101 | Price on request | Contact us for price and availability |
| 18 | 30152904 | Ferrari Pivot Bush - 30152904 | $24.15 | Available, ships in 3-6 days |
| 19 | 400886 | Ferrari Pin - 400886 | $48.70 | Available, ships in 3-6 days |
| 20 | 16043424 | Ferrari Bolt M8 x 20 - 16043424 | $0.38 | Available, ships in 3-6 days |
| 20 | 16043411 | Ferrari Hex Head Screw - 16043411 | Superseded | Order 16043424 instead |
| 22 | 30064901 | Ferrari Reinforcement - 30064901 | $151.36 | Available, ships in 3-6 days |
| 16043421 | Ferrari Bolt - 16043421 | Superseded | Order 16043424 instead | |
| 11087976 | Ferrari Circlip - 11087976 | Superseded | Order 11087974 instead | |
| 16100812 | Ferrari Nut - 16100812 | Superseded | Order 16100824 instead | |
| 16100814 | Ferrari Nut - 16100814 | Superseded | Order 16100824 instead | |
| 10615674 | Ferrari Washer - 10615674 | Superseded | Order 12601374 instead | |
| 680232 | Ferrari Washer - 680232 | Superseded | Order 12601274 instead | |
| 12605374 | Ferrari Wavy Washer - 12605374 | Superseded | Order 12601274 instead | |
| - | 30005508 | Ferrari Head Lamp Perspex Cover - 30005508 | $667.33 | Available, ships in 3-6 days |
| - | 0401154 | Ferrari LH HEADLIGHT MOTOR ASSY - 0401154 | Price on request | Contact us for price and availability |
| - | 30072003 | Ferrari Lower Perspex Cover Surround - 30072003 | $728.24 | Special order, ships in 7-14 days |
| - | 0401153 | Ferrari RH HEADLIGHT MOTOR ASSY - 0401153 | Price on request | Contact us for price and availability |
| - | 30071906 | Ferrari Upper Perspex Cover Surround - 30071906 | $704.20 | Available, ships in 3-6 days |
